约翰迪尔零件查询310SK TC - BACKHOE, LOADER Transmission Input Shaft and Clutch DiskEPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 620 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT339915	[1]	Tapered Roller Bearing
2.	T229356	[2]	Thrust Washer
3.	L77096	[2]	Needle Bearing	SUB FOR JD37406
4.	T341152	[2]	Tapered Roller Bearing	SUB FOR T158749
5.	T229412	[1]	Hub
6.	AT339920	[2]	Needle Bearing
7.	40M7058	[2]	Snap Ring
8.	T229468	[1]	Round Retainer
9.	T229346	[1]	Compression Spring
10.	T341153	[1]	Snap Ring	2.00 MM SUB FOR T262843 AND T229381
10.	T341154	[1]	Snap Ring	2.25 MM SUB FOR T262844 AND T229352
10.	T341155	[1]	Snap Ring	2.50 MM SUB FOR T262845 AND (1) T229379
10.	T341156	[1]	Snap Ring	2.75 MM SUB FOR T262846 AND (1) T229359
10.	T341157	[1]	Snap Ring	3.00 MM SUB FOR T262847 AND T229380
10.	T341158	[1]	Snap Ring	3.25 MM SUB FOR T262848 AND T229364
10.	T341159	[1]	Snap Ring	3.50 MM SUB FOR T262870 AND T229341
10.	T341160	[1]	Snap Ring	3.75 MM
10.	T341161	[1]	Snap Ring	4.00 MM
11.	T229340	[1]	Disk With Outer Spline
12.	AT339922	[10]	Clutch Disk
13.	AT364830	[1]	Round Retainer	SUB FOR (1) T229469
14.	T229398	[1]	O-Ring
15.	T229403	[1]	Piston
16.	AT258980	[1]	O-Ring	40 X 3 MM (1.575" X 0.118")
17.	T229406	[10]	Plate
18.	L153002	[1]	Piston Ring
19.	AT339910	[1]	Modular Clutch
20.	T172118	[3]	Piston Ring
21.	AT435599	[1]	Tapered Roller Bearing	SUB FOR AT339914
22.	T229335	[1]	Shaft
23.	AT339899	[1]	Ball Bearing
24.	40M7047	[1]	Snap Ring
25.	40M5099	[1]	Snap Ring
