现代零件查询25/30/33L-7A CABIN ELECTRICEPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
903 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
71HA-50011
|
[1] |
CABIN ASSY
|
|
| -1. |
21HA-30100
|
[1] |
ELEC CABIN ASSY
|
|
| 1. |
21HA-30111
|
[1] |
HARNESS CABIN-1
|
|
| 1. |
21HA-30112
|
[1] |
HARNESS-CAB LH
|
|
| 1. |
21HA-30111
|
[1] |
HARNESS CABIN-1
|
|
| 1. |
21HA-30112
|
[1] |
HARNESS-CAB LH
|
|
| 1. |
21HA-30111
|
[1] |
HARNESS CABIN-1
|
|
| 1. |
21HA-30112
|
[1] |
HARNESS-CAB LH
|
|
| 2. |
21HA-30130
|
[1] |
HARNESS CABIN-2
|
|
| 3. |
21LB-20401
|
[2] |
SPEAKER ASSY
|
|
| 4. |
21N6-10410
|
[1] |
ANTENA
|
|
| 5. |
21HA-20100
|
[1] |
WIPER MOTOR
|
|
| 6. |
21M8-50210
|
[1] |
WIPER ARM ASSY
|
|
| 6. |
21HA-30150
|
[1] |
WIPER ARM ASSY
|
|
| 7. |
21N6-01230
|
[1] |
BLADE-WIPER
|
|
| 8. |
21E3-3008
|
[1] |
TANK-WASHER
|
|
| 9. |
24L3-41500
|
[1] |
VALVE-WIPER
|
|
| 10. |
21EM-10890
|
[1] |
HOSE-WASHER TANK
|
|
| 11. |
21M6-53300
|
[1] |
SWITCH-WIPER/WASHER
|
|
| 12. |
21M5-0304
|
[1] |
LAMP-ROOM
|
|
| N12-1. |
S864-012210
|
[1] |
BULB
|
|
| 13. |
F12840011
|
[2] |
LAMP SUB ASSY-WORK
|
|
| 13. |
21HF-25100
|
[3] |
LAMP SUB ASSY-WORK
|
|
| 13-1. |
S866-120550
|
[1] |
BULB
|
|
| 14. |
21HL-10220
|
[2] |
LAMP-FLASHER
|
|
| 15. |
F12840050
|
[2] |
COMB LAMP ASSY-RR
|
|
| 15. |
21HA-20410
|
[2] |
LAMP-COMBINATION
|
|
| 15. |
F12840050
|
[2] |
COMB LAMP ASSY-RR
|
|
| 15. |
21HA-20410
|
[2] |
LAMP-COMBINATION
|
|
| 15. |
F12840050
|
[2] |
COMB LAMP ASSY-RR
|
|
| 15. |
21HA-20410
|
[2] |
LAMP-COMBINATION
|
|
| 15-1. |
S861-021000
|
[1] |
BULB(12V 10W)
|
|
| 15-1. |
S861-072300
|
[1] |
BULB(12V 23W)
|
|
| 15-1. |
S863-072308
|
[1] |
BULB(12V 23/8W)
|
|
| 20. |
S161-050106
|
[8] |
SCREW-CROSS R/RD
|
|
| 21. |
S411-050006
|
[8] |
WASHER-SPRING
|
|
| 22. |
S151-040156
|
[2] |
SCREW-TAPPING
|
|
| 23. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 24. |
S132-061526
|
[2] |
SCREW-W/WASHER
|
|
