约翰迪尔零件查询315CH - BACKHOE, LOADER TRANSMISSION CASE (WITHOUT FOUR WHEEL DRIVE) (SERIAL NO. -761934) [01C17]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
666 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T100628
|
[1] |
Trough
|
|
| 2. |
15H562
|
[1] |
Pipe Plug
|
|
| 3. |
14H971
|
[1] |
Nut
|
|
| 4. |
T18891
|
[1] |
Plug
|
|
| 5. |
T21937
|
[1] |
Plug
|
|
| 6. |
15H584
|
[1] |
Pipe Plug
|
|
| 7. |
R48685
|
[4] |
Dowel Pin
|
|
| 8. |
U17409
|
[1] |
O-Ring
|
|
| 9. |
T78662
|
[1] |
Drain Plug
|
|
| 10. |
R27490
|
[1] |
O-Ring
|
|
| 11. |
T21776
|
[1] |
Screw
|
|
| 12. |
T113166
|
[2] |
Plug
|
|
| 13. |
R39112
|
[1] |
Fitting
|
|
| 14. |
R26375
|
[1] |
O-Ring
|
|
| 15. |
AT166581
|
[1] |
Transmission Case
|
|
| 16. |
19H1648
|
[1] |
Cap Screw
|
|
| 17. |
24M1606
|
[1] |
Washer
|
|
| 18. |
R62129
|
[1] |
Needle Roller
|
|
| 19. |
22H993
|
[1] |
Set Screw
|
|
| 20. |
T118848
|
[1] |
Seal
|
|
| 21. |
19H2367
|
[1] |
Cap Screw
|
|
| 22. |
R26906
|
[2] |
O-Ring
|
|
| 23. |
T58477
|
[2] |
Fitting
|
|
