约翰迪尔零件查询315CH - BACKHOE, LOADER RADIATOR AND RADIATOR HOSES [01D21]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
458 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT114233
|
[1] |
Bracket
|
|
| 1. |
T105718
|
[3] |
Isolator
|
|
| 2. |
19M7864
|
[2] |
Screw
|
|
| 3. |
AT165587
|
[1] |
Filler Cap
|
|
| 4. |
AT129143
|
[1] |
Radiator
|
|
| 5. |
19M8081
|
[2] |
Cap Screw
|
|
| 6. |
24M7101
|
[AR] |
Washer
|
|
| 7. |
U42208
|
[2] |
Isolator
|
|
| 8. |
15H220
|
[1] |
Elbow Fitting
|
|
| 9. |
AT13740
|
[1] |
Drain Valve
|
|
| 10. |
14M7296
|
[2] |
Flange Nut
|
|
| 11. |
AR40418
|
[3] |
Hose Clamp
|
|
| 12. |
T113263
|
[1] |
Radiator Hose
|
|
| 13. |
AR21999
|
[1] |
Hose Clamp
|
|
| 14. |
T113264
|
[1] |
Radiator Hose
|
|
| 15. |
T113563
|
[2] |
Spacer
|
|
