约翰迪尔零件查询315CH - BACKHOE, LOADER FUEL TANK, FUEL HOSES AND FUEL GAUGE SENDER [01E07]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 935 次

Pos.	Part No	Qty	Parts name	Comments
1.	21H1300	[5]	Screw	0.190" X 3/8"
2.	AT81470	[1]	Sender	(REQUIRES TY6350 LUBRICANT)
3.	T211051	[1]	Gasket	(SUB FOR U42323)
4.	AM115497	[1]	Filler Cap	(SUB FOR AT100102, THIS APPLICATION)
5.	T113265	[1]	Fuel Tank
6.	24H1335	[2]	Washer	15/32" X 2-1/2" X 0.105"
7.	19M8081	[2]	Cap Screw	M10 X 80
8.	AR21999	[1]	Hose Clamp
9.	AT65241	[1]	Strainer
9.	TY15969	[1]	Adhesive
10.	T68303	[1]	Fitting
11.	T12269	[1]	Fitting
12.	........	[1]	Hose	(MAKE FROM M87571 BULK MATERIAL, CUT TO LENGTH)
13.	AT124350	[1]	Hand Operated Valve	(SUB FOR AT18853)
14.	........	[1]	Hose	(MAKE FROM M87571 BULK MATERIAL, CUT TO LENGTH)
15.	TY22462	[4]	Clamp	(SUB FOR AR48236)
16.	28H1497	[2]	Bushing	0.493" X 0.675" X 1-1/2"
17.	TY22464	[2]	Clamp	(SUB FOR AR21836)
18.	T12269	[1]	Fitting
19.	X4-4FTX-S	[1]	Adapter Fitting	(SUB FOR T36253)
20.	AT17384	[1]	Hose	7/16" X 356 MM (14") X 1/8"
21.	H77698	[1]	Tie Band	(SUB FOR T44946)
22.	........	[2]	Conduit	(SUB FOR T119099) (MAKE FROM T122040 BULK MATERIAL, CUT TO LENGTH)
23.	H77698	[8]	Tie Band	(SUB FOR T44946)
