约翰迪尔零件查询401C - BACKHOE, LOADER ROCKER ARMS AND VALVES [01B05]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询401C - BACKHOE, LOADER ROCKER ARMS AND VALVES [01B05]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 712 次

Pos.	Part No	Qty	Parts name	Comments
1.	R87627	[8]	O-Ring	(GASOLINE) (SUB FOR R27976, THIS APPLICATION)
2.	RE31973	[8]	Rocker Arm	(SUB FOR AT31250, AR103769 AND RE19031)
3.	T32213	[1]	Screw	(SUB RE31973)
4.	19H3031	[4]	Cap Screw	3/8" X 2-1/2"
5.	R42729	[4]	Washer	(SUB FOR T23594)
6.	T20316	[2]	Washer
7.	R54565	[2]	Plug
8.	RE502874	[1]	Rocker Arm Shaft
9.	T20077	[16]	Retainer
10.	T20287	[4]	Rotator	(GASOLINE)
10.	R41412	[4]	Cap	(DIESEL) (SUB FOR T20176)
11.	R26125	[8]	Spring
12.	R79624	[4]	Exhaust Valve	(DIESEL) STANDARD STEM, (SUB FOR R52252)
12.	R79625	[4]	Exhaust Valve	(SUB FOR T23549 AND R57333) 0.08 MM (.003") OVERSIZE STEM (DIESEL)
12.	R79626	[4]	Exhaust Valve	(SUB FOR T23550 AND R57335) 0.38 MM (.015") OVERSIZE STEM (DIESEL)
12.	........	[4]	Exhaust Valve	(SUB FOR T23551 AND R57337) ( R79627 NO LONGER AVAILABLE) 0.76 MM (.030") OVERSIZE STEM (DIESEL)
12.	T25467	[4]	Exhaust Valve	(GASOLINE) STANDARD STEM
12.	T26178	[4]	Exhaust Valve	(SUB FOR T23543) 0.08 MM (.003") OVERSIZE STEM (GASOLINE)
12.	T26179	[4]	Exhaust Valve	0.38 MM (.015") OVERSIZE STEM (GASOLINE) (SUB FOR T23544)
12.	T26180	[4]	Exhaust Valve	0.76 MM (.030") OVERSIZE STEM (GASOLINE) (SUB FOR T23545)
13.	T20073	[8]	Tappet
14.	R82896	[8]	Push Rod	(DIESEL) (SUB FOR T20310)
14.	T22893	[8]	Pin	(GASOLINE)
15.	R79623	[4]	Intake Valve	(DIESEL) STANDARD STEM, (SUB FOR R52251)
15.	R79628	[4]	Intake Valve	(SUB FOR T23546 AND R57332) 0.08 MM (.003") OVERSIZE STEM (DIESEL)
15.	R79629	[4]	Intake Valve	(SUB FOR T23547 AND R57334) 0.38 MM (.015") OVERSIZE STEM (DIESEL)
15.	........	[4]	Intake Valve	(SUB FOR T23548 AND R57336) ( R79630 NO LONGER AVAILABLE) 0.76 MM (.030") OVERSIZE STEM (DIESEL)
15.	T25466	[4]	Intake Valve	(GASOLINE) STANDARD STEM
15.	T23540	[4]	Intake Valve	0.08 MM (.003") OVERSIZE STEM (GASOLINE)
15.	T26176	[4]	Intake Valve	0.38 MM (.015") OVERSIZE STEM (GASOLINE)
15.	........	[4]	Intake Valve	0.76 MM (.030") OVERSIZE STEM (GASOLINE) ( T26177 - NO LONGER AVAILABLE)
16.	R41412	[4]	Cap	(DIESEL) (SUB FOR T20176)
17.	T20315	[4]	Support	(SUB RE502861) (USE WITH 19H3031 AND R54987)
18.	T20314	[3]	Spring
19.	R54987	[1]	Rocker Arm Shaft	(SUB RE502874) (SUB FOR R54987) (USE WITH 19H3031 AND T20315)
20.	R123513	[1]	Rocker Arm Shaft
21.	R504813	[AR]	Screw	(SUB FOR R501529)
21.	19H3031	[AR]	Cap Screw	3/8" X 2-1/2"
22.	R123161	[4]	Support
23.	T20129	[8]	Cap	(DIESEL)
24.	RE502861	[1]	Support
