约翰迪尔零件查询401C - BACKHOE, LOADER AIR CLEANER (DRY-TYPE) [01C04]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
619 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H2021
|
[2] |
Cap Screw
|
|
| 2. |
12H304
|
[3] |
Lock Washer
|
|
| 3. |
M1335T
|
[1] |
Washer
|
|
| 4. |
AR21999
|
[6] |
Hose Clamp
|
|
| 4. |
AR21999
|
[2] |
Hose Clamp
|
|
| 5. |
T23084
|
[1] |
Hose
|
|
| 6. |
AL28179
|
[1] |
Air Cleaner
|
|
| 7. |
........
|
[1] |
Pipe
|
|
| 8. |
AT20728
|
[1] |
Filter Element
|
|
| 9. |
AT24437
|
[1] |
Wing Screw
|
|
| 10. |
AT81398
|
[1] |
Cover
|
|
| 11. |
........
|
[1] |
Pipe
|
|
| 11. |
T22830
|
[1] |
Pipe
|
|
| 12. |
R53443
|
[1] |
Hose
|
|
| 13. |
R56551
|
[1] |
Hose
|
|
| 14. |
19H2284
|
[1] |
Cap Screw
|
|
| 15. |
T23263
|
[1] |
Valve
|
|
| 16. |
15H638
|
[1] |
Pipe Plug
|
|
