约翰迪尔零件查询401C - BACKHOE, LOADER CLUTCH HOUSING (WITHOUT REVERSER) [01E07]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 880 次

Pos.	Part No	Qty	Parts name	Comments
1.	T21827	[1]	Washer	(WITHOUT TACHOMETER)
2.	T22898	[1]	Plug	(WITHOUT TACHOMETER)
3.	R39112	[1]	Fitting
4.	R26375	[1]	O-Ring
5.	19H2510	[2]	Cap Screw	HS, SAE 8, 1/2" X 1-5/8"
6.	T20168	[5]	Washer
7.	T12083	[1]	Plug	(A)
8.	19H2735	[1]	Cap Screw	HS, SAE 8, 1/2" X 2"
9.	T22851	[1]	Washer
9.	T68412	[1]	Washer
10.	19H1895	[1]	Cap Screw	(A) 1/2" X 3/4"
11A.	T30841	[1]	Adapter	(A) (SUB T25408, R64806 AND R375R)
11B.	T25408	[1]	Sleeve	(A)
12A.	T30842	[1]	Tube	(A) (SUB R64806, T25408 AND R375R)
12B.	R48290	[1]	Oil Tube	(A) (SUB R64806)
12B.	R64806	[1]	Oil Tube	(A)
13.	15H638	[1]	Pipe Plug	1/8"
14.	A4847R	[1]	Washer
15.	AT41646	[1]	Housing	(INCLUDES ALL PARTS IDENTIFIED BY (A) (MARKED T42716) (SUB AT65217) (ALSO ORDER (2) T68412)
15.	AT65217	[1]	Housing	(INCLUDES ALL PARTS IDENTIFIED BY (A) (MARKED T67962)
16.	R99290	[1]	Gasket	(SUB FOR T21968)
17.	R27175	[1]	Drain Plug
18.	U12547	[1]	O-Ring	(SUB FOR F3171R)
19.	T22850	[1]	Pin
20.	F2772R	[1]	Ball	(A)
21.	T22858	[1]	Valve Seat Insert	(A)
22.	14H812	[4]	Nut	3/8"
23.	R30958	[4]	Lock Plate
24.	C2175R	[4]	Stud	(A)
25.	T14059	[1]	Spring
26.	L1788C	[1]	Bushing	(A)
27.	R1680R	[2]	Plug	(SUB FOR T22569, THIS APPLICATION)
28.	T21448	[1]	Pin Fastener	(A)
29.	M4224T	[1]	Plug
30.	19H2644	[2]	Cap Screw	HS, SAE 8, 1/2" X 2-1/2"
31.	T21446	[1]	Bushing	(A)
32.	19H3170	[4]	Cap Screw	5/8" X 4-1/2"
32.	19H3170	[3]	Cap Screw	HS, SAE 8, 5/8" X 4-1/2"
33.	19M7084	[1]	Cap Screw	M8 X 15
34.	R70268	[4]	Washer	(SUB FOR (4) R42363)
35.	T21447	[1]	Sleeve	(A)
36.	R26919	[1]	Washer
37.	R375R	[1]	O-Ring	(A)
38.	M1102T	[1]	Plug
39.	L29854	[1]	Stud
40.	14H1039	[1]	Nut	5/8"
