约翰迪尔零件查询401C - BACKHOE, LOADER REVERSER CLUTCH CONTROL VALVE AND PISTON [01F01]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
750 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H2932
|
[6] |
Screw
|
|
| 2. |
24H1286
|
[6] |
Washer
|
|
| 3. |
R72874
|
[1] |
Gasket
|
|
| 4. |
F3366R
|
[1] |
Snap Ring
|
|
| 5. |
R72654
|
[2] |
Snap Ring
|
|
| 6. |
R31319
|
[1] |
Pin
|
|
| 7. |
T39520
|
[1] |
Valve
|
|
| 8. |
R39137
|
[1] |
Spring
|
|
| 9. |
R39140
|
[1] |
Pin Fastener
|
|
| 10. |
R54579
|
[1] |
Housing
|
|
| 11. |
AR39043
|
[2] |
Seal
|
|
| 12. |
R39164
|
[1] |
Plug
|
|
| 13. |
R26906
|
[1] |
O-Ring
|
|
| 14. |
R33277
|
[1] |
Spring
|
|
| 15. |
D2361R
|
[1] |
Ball
|
|
| 16. |
R39294
|
[1] |
Pin Fastener
|
|
| 17. |
F3322R
|
[1] |
Spring
|
|
| 18. |
R39133
|
[1] |
Spring
|
|
| 19. |
R39229
|
[1] |
Spring
|
|
| 20. |
R63364
|
[1] |
Piston
|
|
| 21. |
34H310
|
[1] |
Spring Pin
|
|
| 22. |
R39149
|
[1] |
Valve
|
|
| 23. |
R34028
|
[1] |
Bolt
|
|
| 24. |
R87627
|
[1] |
O-Ring
|
|
| 25. |
R39158
|
[1] |
Cover
|
|
| 26. |
R26287
|
[1] |
O-Ring
|
|
| 27. |
R27216
|
[1] |
Drain Plug
|
|
| 28. |
R26287
|
[2] |
O-Ring
|
|
| 29. |
R27216
|
[2] |
Drain Plug
|
|
| 30. |
T113380
|
[1] |
Pressure Relief Valve
|
|
