现代零件查询25/30/33L-7M CARR & B/REST (QF-MAST, 30L-7M)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
679 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
6CHN-26010
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26011
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26012
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26020
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26021
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26022
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26030
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26031
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26032
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26011
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26021
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1. |
6CHN-26031
|
[1] |
CARR & B/REST SUB ASSY
|
|
| 1-1. |
6CHN-22010
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22011
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22012
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22020
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22021
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22022
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22030
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22031
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22032
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22011
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22021
|
[1] |
CARRIAGE WA
|
|
| 1-1. |
6CHN-22031
|
[1] |
CARRIAGE WA
|
|
| 1-2. |
6AHN-24431
|
[1] |
BACKREST WA
|
|
| 1-2. |
6AHN-24631
|
[1] |
BACKREST WA
|
|
| 1-2. |
6AHN-24731
|
[1] |
BACKREST WA
|
|
| 1-3. |
S017-120356
|
[4] |
BOLT-HEX
|
|
| 1-4. |
S441-12000B
|
[4] |
WASHER-HARDENED
|
|
| 2. |
63HK-18100
|
[1] |
LOAD R/BRG ASSY(117.5)
|
|
| 2. |
63HK-18101
|
[1] |
LOAD R/BEARING(117.5)
|
|
| 2. |
63HK-18110
|
[1] |
LOAD R/BRG ASSY(117.2)
|
|
| 2. |
63HK-18111
|
[1] |
LOAD R/BEARING(117.2)
|
|
| 2. |
63HK-18120
|
[1] |
LOAD R/BRG ASSY(117.8)
|
|
| 2. |
63HK-18121
|
[1] |
LOAD R/BEARING(117.8)
|
|
| 2. |
63HK-18130
|
[1] |
LOAD R/BRG ASSY(116.9)
|
|
| 2. |
63HK-18141
|
[1] |
LOAD R/BEARING(118.1)
|
|
| 3. |
6600187900
|
[1] |
SHIM(0.5T)
|
|
| 4. |
6600188000
|
[1] |
SHIM(1.0T)
|
|
| 5. |
61F7-28010
|
[1] |
BOLT-FLAT HD
|
|
| 6. |
61F7-28021
|
[1] |
WASHER-RETAINING
|
|
| 7. |
61F7-28100
|
[1] |
SIDE ROLLER ASSY
|
|
| 7. |
61F7-28100
|
[2] |
SIDE ROLLER ASSY
|
|
| 8. |
61HM-28040
|
[1] |
ADJUSTABLE SCREW
|
|
| 8. |
61HM-28040
|
[4] |
ADJUSTABLE SCREW
|
|
| 9. |
S205-161006
|
[1] |
NUT-HEX
|
|
| 9. |
S205-161006
|
[4] |
NUT-HEX
|
|
| 10. |
S109-120206
|
[1] |
BOLT-SOCKET
|
|
