Pos.	Part No	Qty	Parts name	Comments
1.	T38554	[1]	Spindle
2.	AT20703	[1]	Seal	OUTER
3.	L35542	[1]	Guide	(SUB FOR T21429)
4.	JD8946	[1]	Bearing Cone	OUTER
5.	JD8206	[1]	Bearing Cup	OUTER
6.	JD7781	[1]	Lubrication Fitting	1/8", (SUB FOR JD7759, THIS APPLICATION)
7.	R27216	[1]	Drain Plug	(SUB FOR R31631)
8.	R26287	[1]	O-Ring
9.	19H1805	[12]	Cap Screw	1/2" X 2-1/4", (WITHOUT PARKING BRAKE)
9.	19H1805	[10]	Cap Screw	1/2" X 2-1/4", (WITH PARKING BRAKE)
9.	19H3057	[2]	Cap Screw	1/2" X 2-3/4", (WITH PARKING BRAKE)
10.	R21612	[1]	Bleed Valve
11.	AT40757	[1]	Housing	INCLUDES HOUSING (MARKED T41733) AND GEAR (MARKED R57200) (ALSO ORDER (3) T21428 AND (3) R36666) (SUB AT106669)
11.	AT169364	[1]	Housing	(MARKED T105800) (SUB FOR AT74432 MARKED T76229 AND GEAR MARKED R57200 AND AT106669 MARKED T105800 AND GEAR MARKED R57200)
11.	T151158	[1]	Ring Gear	(MARKED R57200) (USE WITH AT106669) (MARKED T105800) (SUB FOR T125844) (MARKED R57200) (NOT ILLUSTRATED)
12.	T21428	[3]	Dowel Pin
13.	R98915	[1]	Gasket	(SUB FOR T21419)
14.	AT124396	[1]	Seal	INNER, (SUB FOR AT16887)
15.	JD8206	[1]	Bearing Cup	INNER
16.	JD8151	[1]	Bearing Cone
17.	R36666	[3]	Dowel Pin
18.	R47862	[1]	Cap
