现代零件查询25/30/33L-7M CABIN 1EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
731 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
71HA-50013
|
[1] |
CABIN ASSY
|
|
| 1. |
71HA-50023
|
[1] |
CABIN WA
|
|
| 4. |
71HA-57003
|
[1] |
REAR DOOR ASSY-LH
|
|
| 4-1. |
71HA-57103
|
[1] |
REAR DOOR WA
|
|
| 4-2. |
71HA-57203
|
[1] |
DOOR INNER
|
|
| 4-3. |
71HA-55611
|
[8] |
FASTENER
|
|
| 4-4. |
71HA-57910
|
[1] |
WEATHER STRIP
|
|
| 4-5. |
71HA-57302
|
[1] |
GLASS-REAR LH
|
|
| 4-6. |
71HA-57920
|
[1] |
WEATHER STRIP
|
|
| 4-7. |
71HA-57401
|
[1] |
PAD-BONDING
|
|
| 4-8. |
S771-007200
|
[1] |
WEATHER STRIP
|
|
| 4-12. |
71HA-57501
|
[1] |
HINGE ASSY-LH
|
|
| 4-13. |
71HA-57601
|
[1] |
HINGE ASSY-LH
|
|
| 4-14. |
71HA-55840
|
[4] |
SCREW
|
|
| 4-15. |
71HA-57701
|
[1] |
PLATE-HINGE
|
|
| 4-16. |
71HA-57801
|
[1] |
PLATE-HINGE
|
|
| 4-18. |
71HA-57901
|
[1] |
PAD-SPONGE
|
|
| 5. |
71HA-58003
|
[1] |
REAR DOOR ASSY-RH
|
|
| 5-1. |
71HA-58103
|
[1] |
REAR DOOR WA
|
|
| 5-2. |
71HA-58203
|
[1] |
DOOR INNER
|
|
| 5-3. |
71HA-55611
|
[8] |
FASTENER
|
|
| 5-4. |
71HA-57910
|
[1] |
WEATHER STRIP
|
|
| 5-5. |
71HA-58302
|
[1] |
GLASS-REAR RH
|
|
| 5-6. |
71HA-57920
|
[1] |
WEATHER STRIP
|
|
| 5-7. |
71HA-57401
|
[1] |
PAD-BONDING
|
|
| 5-11. |
71HA-58501
|
[1] |
HINGE ASSY-RH
|
|
| 5-12. |
71HA-58601
|
[1] |
HINGE ASSY-RH
|
|
| 5-13. |
71HA-55840
|
[4] |
SCREW
|
|
| 5-14. |
71HA-57701
|
[1] |
PLATE-HINGE
|
|
| 5-15. |
71HA-57801
|
[1] |
PLATE-HINGE
|
|
| 5-16. |
71HA-57901
|
[1] |
PAD-SPONGE
|
|
| 7. |
71HA-55840
|
[8] |
SCREW
|
|
| 10. |
51FA-90040
|
[2] |
COVER-AIR INTAKE
|
|
| 10. |
51FA-90040
|
[1] |
COVER-AIR INTAKE
|
|
| 10. |
51FA-90040
|
[2] |
COVER-AIR INTAKE
|
|
| 10. |
51FA-90040
|
[1] |
COVER-AIR INTAKE
|
|
| 10. |
51FA-90040
|
[2] |
COVER-AIR INTAKE
|
|
| 10. |
51FA-90040
|
[1] |
COVER-AIR INTAKE
|
|
| 11. |
71HF-31240
|
[2] |
PAD-RUBBER
|
|
| 48. |
S035-081526
|
[2] |
BOLT-W/WASHER
|
|
| 48. |
S035-081526
|
[2] |
BOLT-W/WASHER
|
|
| 48. |
S035-081526
|
[2] |
BOLT-W/WASHER
|
|
| 60. |
71HN-34300
|
[1] |
CLOSED COVER
|
|
| 60. |
71HN-34300
|
[1] |
CLOSED COVER
|
|
| 60. |
71HN-34300
|
[1] |
CLOSED COVER
|
|
| 61. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 61. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
| 61. |
S035-061526
|
[2] |
BOLT-W/WASHER
|
|
