约翰迪尔零件查询401C - BACKHOE, LOADER PRESSURE CONTROL VALVE (SERIAL NO. 339545- ) [01H04]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 502 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT35120	[1]	Elbow Fitting	(B)
2.	R26448	[1]	O-Ring	(B)
3.	R27270	[1]	Fitting
4.	R26906	[1]	O-Ring	(B)
5.	R39324	[1]	Dowel Pin
6.	19H2633	[1]	Cap Screw	3/8" X 1-1/2"
7.	12H304	[3]	Lock Washer	3/8"
8.	T120368	[1]	Housing	(SUB FOR R39323)
9.	R60332	[1]	O-Ring
10.	R28776	[1]	O-Ring
11.	AR91029	[1]	Oil Line	(B)
12.	R40562	[1]	Aperture
13.	........	[1]	Washer	(SUB AR65882)
14.	R40072	[1]	Spring
15.	R26906	[1]	O-Ring	(B)
16.	24H1283	[AR]	Washer	7/32" X 1/2" X 0.049"
17.	R63494	[1]	Fitting
18.	R27175	[2]	Drain Plug
19.	U12547	[2]	O-Ring	(SUB FOR (2) F3171R)
20.	19H2458	[1]	Cap Screw	3/8" X 3"
21.	19H3483	[1]	Cap Screw	3/8" X 1-1/8"
22.	R26375	[1]	O-Ring	(B)
23.	R27237	[1]	Fitting	(B) (WITH SELECTIVE CONTROL VALVE)
23.	R39112	[1]	Fitting	(WITHOUT SELECTIVE CONTROL VALVE)
24.	R33521	[AR]	Shim	0.76 MM (.030")
25.	AR65882	[1]	Control Valve	(SUB AR65882)
...	AR91861	[1]	Valve	POPPET, DOUBLE ACTING, SINGLE, WITHOUT LEVER LOCK, FOR USE WITH 5.00 TO 1 FINAL DRIVE RATIO, (SUB FOR AR76093) (INCLUDES (2) AR21837, AR99025, (2) R39171, R62147, R77420, R20922, T22996, T23069, (2) 14H732, 19H1895, (2) 19H3597 AND 24H1625)
