现代零件查询25/30/33L-7M MAIN CONTROL VALVE (4-SPOOL,33L-7M)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
902 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
33HN-02051
|
[1] |
MCV-4SPL(NON-OPSS)
|
|
| . |
33HN-02551
|
[1] |
MCV-4SPL(OPSS)
|
|
| 1. |
@
|
[1] |
BLOCK-LIFT
|
|
| 33. |
@
|
[1] |
BLOCK-TILT
|
|
| 43. |
@
|
[4] |
BLOCK-AUX
|
|
| N45. |
402001001
|
[1] |
BLOCK-WORK
|
|
| 62. |
XKAU-00271
|
[1] |
BLOCK-PT,SOL
|
|
| 63. |
XKAU-00272
|
[1] |
SOLENOID VALVE
|
|
| 64. |
31021291950
|
[1] |
BOLT-HEX
|
|
| K. |
XKAU-00423
|
[1] |
LIFT SECTION KIT(NON-OPSS)
|
|
| K. |
XKAU-00424
|
[1] |
LIFT SECTION KIT(OPSS)
|
|
| K. |
XKAU-00426
|
[1] |
TILT SECTION KIT
|
|
| K. |
XKAU-00427
|
[1] |
AUX SECTION KIT
|
|
| K. |
XKAU-00429
|
[1] |
WORK SECTION KIT
|
|
| K. |
XKAU-00430
|
[1] |
LIFT SEAL KIT(NON-OPSS)
|
|
| K. |
XKAU-00431
|
[1] |
LIFT SEAL KIT(OPSS)
|
|
| K. |
XKAU-00432
|
[1] |
TILT SEAL KIT
|
|
| K. |
XKAU-00433
|
[1] |
AUX SEAL KIT
|
|
| K. |
XKAU-00435
|
[1] |
WORK SEAL KIT
|
|
| K. |
XKAU-00400
|
[1] |
SPOOL SEAL KIT
|
|
| K. |
XKAU-00399
|
[1] |
RELIEF VALVE KIT
|
|
| K. |
XKAU-00421
|
[1] |
PT SECTION KIT(OPSS)
|
|
| K. |
XKAU-00422
|
[2] |
PT SECTION KIT(NON-POSS)
|
|
| K. |
XKAU-00420
|
[2] |
TIE BOLT KIT(4-SPL)
|
|
| K. |
XKAU-00417
|
[1] |
FLOW REGULATOR
|
|
| N. |
@
|
[AR] |
NOT SUPPLIED PARTS
|
|
