现代零件查询25/30/33L-7M HYD OIL TANK (25L-7M, FINGER TIP)EPC Hyundai
广数供应链运营团队, 16 02月, 2025，浏览：
474 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
35HF-30041
|
[1] |
TANK FLANGE ASSY
|
|
| 2. |
Y172-027001
|
[1] |
O-RING(AN 계열)
|
|
| 3. |
F42650010
|
[1] |
FILTER-RETURN
|
|
| 4. |
FHC1007100
|
[1] |
STRAINER-SUCTION
|
|
| 5. |
F11663011
|
[1] |
CAP-HYD OIL
|
|
| 6. |
31FF-81640
|
[1] |
HOSE-RUBBER(Ø15.9X400L)
|
|
| 7. |
31FV-30031
|
[1] |
CAP-AIR BREATHER
|
|
| 8. |
F23650200
|
[1] |
FILTER-AIR BREATHER
|
|
| 9. |
31HM-30020
|
[1] |
PLUG-MAGNETIC
|
|
| 10. |
S631-014004
|
[5] |
O-RING
|
|
| 12. |
S035-082026
|
[6] |
BOLT-W/WASHER
|
|
| 13. |
11F1-5032
|
[1] |
CAP-RUBBER
|
|
| 14. |
S035-062026
|
[1] |
BOLT-W/WASHER
|
|
| 16. |
31HA-20170
|
[1] |
CONNECTOR-BULK HOSE
|
|
| 17. |
P220-110103
|
[3] |
PLUG-HEX
|
|
| 21. |
35HF-30070
|
[1] |
CONNECTOR
|
|
| 22. |
S520-027000
|
[3] |
CLAMP-HOSE
|
|
| 23. |
S411-060006
|
[1] |
WASHER-SPRING
|
|
