约翰迪尔零件查询401C - BACKHOE, LOADER FRONT SUPPORT [01K08]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
119 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H2358
|
[2] |
Cap Screw
|
|
| 2. |
12H317
|
[2] |
Lock Washer
|
|
| 3. |
T26929
|
[2] |
Bushing
|
|
| 4. |
AR72474
|
[1] |
Support
|
|
| 5. |
T22375
|
[1] |
Pad
|
|
| 6. |
12H294
|
[4] |
Lock Washer
|
|
| 7. |
19H2641
|
[4] |
Cap Screw
|
|
| 8. |
T21540
|
[2] |
Pad
|
|
| 9. |
T23118
|
[1] |
Bushing
|
|
| 10. |
JD7799
|
[1] |
Lubrication Fitting
|
|
| 11. |
T22864
|
[1] |
Cover
|
|
| 12. |
19H2021
|
[2] |
Cap Screw
|
|
| 13. |
12H304
|
[2] |
Lock Washer
|
|
| 14. |
R54195
|
[1] |
Spring Pin
|
|
| 15. |
T24160
|
[2] |
Snap Ring
|
|
| 16. |
C15599
|
[AR] |
Washer
|
|
