约翰迪尔零件查询410 - BACKHOE, LOADER AIR CLEANER, AIR INTAKE PIPES AND HOSES (SERIAL NO. -387066) [01C13]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询410 - BACKHOE, LOADER AIR CLEANER, AIR INTAKE PIPES AND HOSES (SERIAL NO. -387066) [01C13]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 738 次

Pos.	Part No	Qty	Parts name	Comments
1.	19H2021	[2]	Cap Screw	3/8" X 5/8"
2.	12H304	[3]	Lock Washer	3/8"
3.	AR21999	[3]	Hose Clamp	(DIESEL)
3.	AR21999	[4]	Hose Clamp	(GASOLINE)
4.	T31144	[1]	Hose	AIR INTAKE PIPE, FRONT (DIESEL)
4.	R55266	[1]	Hose
4.	T23084	[1]	Hose	(GASOLINE)
5.	AR21841	[1]	Clamp	(DIESEL)
6.	T33169	[1]	Pipe	(SUB FOR AT30989) (ALSO ORDER T22385) (DIESEL)
7.	T11586	[1]	Hose	REAR (DIESEL)
8.	AT32436	[1]	Pipe	(GASOLINE) (NO LONGER AVAILABLE, ORDER T22385 AND T33168)
9.	R56551	[1]	Hose	(SUB FOR T21703) (GASOLINE)
10.	19H2284	[1]	Cap Screw	3/8" X 7/8"
11.	AT81398	[1]	Cover	(SUB FOR AT24438)
12.	AT24437	[1]	Wing Screw
13.	AT20728	[1]	Filter Element
14.	15H638	[1]	Pipe Plug	1/8", (WITHOUT RESTRICTION INDICATOR)
15.	AL28179	[1]	Air Cleaner	(SUB FOR AT20727, THIS APPLICATION)
16.	AR44361	[1]	Fitting	(WITH RESTRICTION INDICATOR)
17.	AT25983	[1]	Air Restriction Indicator	(DIESEL)
17.	AT26536	[1]	Air Restriction Indicator	(GASOLINE)
18.	T23263	[1]	Valve	(MADE IN GERMANY)
19.	M1335T	[1]	Washer
20.	T22385	[1]	Pad	(NO LONGER AVAILABLE)
...	........	[1]	Air Restriction Indicator	AIR CLEANER RESTRICTION (DIESEL) ( AT23508 USE IF AVAILABLE)
