约翰迪尔零件查询410 - BACKHOE, LOADER RADIATOR AND TRANSMISSION OIL COOLER [01C23]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 661 次

Pos.	Part No	Qty	Parts name	Comments
1.	T11234	[2]	Lock Nut
2.	24H1305	[2]	Washer	13/32" X 13/16" X 0.065"
3.	T33399	[1]	Eyebolt
4.	24H1122	[1]	Washer	3/8" X 7/8" X 0.083"
5.	19H2664	[1]	Cap Screw	5/16" X 3/4"
6.	AT27585	[1]	Cap
7.	14H785	[5]	Nut	5/16"
8.	12H303	[5]	Lock Washer	5/16"
9.	24H1685	[4]	Washer	11/32" X 47/64" X 0.083"
10.	AT35182	[1]	Oil Cooler	(SUB AT165536 AND T113380 OIL COOLER RELIEF VALVE)
10.	AT165536	[1]	Oil Cooler	(SUB FOR AT33887) HYDRAULIC
11.	AR21840	[2]	Hose Clamp
12.	T33401	[1]	Hose	UPPER (DIESEL)
12.	T33370	[1]	Hose	(GASOLINE)
13.	AR21840	[2]	Hose Clamp
14.	T22500	[1]	Hose	LOWER
15.	AR21839	[2]	Clamp	(SUB FOR H2742B, THIS APPLICATION)
16.	........	[1]	Hose	19 MM X 57 MM (3/4" X 2-1/4") CLUTCH HOUSING OIL LINE (MAKE FROM T61939 BULK MATERIAL, CUT TO LENGTH) (SUB FOR T35690)
17.	T22381	[2]	Washer
18.	R62372	[2]	Spring	(SUB FOR R34352)
19.	19H2458	[2]	Cap Screw	3/8" X 3"
20.	T36226	[1]	Foam Pad
20.	T35773	[1]	Pad
21.	AT13740	[1]	Drain Valve
22.	........	[1]	Strip	(CUT ONE STRIP 20" LONG FROM R35416 STOCK)
23.	AT32589	[1]	Radiator	(SUB AT32591)
23.	AT32591	[1]	Radiator
24.	T36499	[1]	Barrier
25.	T37175	[2]	Nut
...	T11847	[1]	Sealant	(NO LONGER AVAILABLE)
...	RE12842	[1]	Coolant	(.91 KG (32 OZ.) CAN) (SUB FOR T19566)
