Pos.	Part No	Qty	Parts name	Comments
1.	T20243	[1]	Gasket
2.	T26851	[1]	Cover
3.	T20242	[1]	Gasket
4.	T30897	[1]	Impeller	(SUB FOR T30897 OR R94419)
5.	T27261	[1]	Seal	(SUB AR101549)
6.	JD9257	[1]	Ball Bearing
7.	T19653	[1]	Elbow Fitting
8.	T29521	[1]	Housing	(SUB RE19719)
9.	T24757	[1]	V-Belt
10.	T23628	[1]	Pulley	(SUB FOR T30721) (ALSO ORDER (4) 19H3467)
11.	19H1912	[2]	Cap Screw	3/8" X 3-1/2"
12.	12H304	[5]	Lock Washer	3/8"
12.	12H304	[4]	Lock Washer	3/8", (USE WITH R62371)
13.	14H812	[1]	Nut	3/8"
14.	19H3385	[3]	Cap Screw	1/2" X 1-1/8"
15.	19H1726	[1]	Cap Screw	3/8" X 2-1/4"
16.	R108404	[1]	Strap	ALTERNATOR, (SUB FOR T20204 AND R107734)
17.	T25701	[1]	Stud
18.	AT170040	[1]	Fan	(SIX OR SEVEN BLADE FAN) (SUB FOR AT35158)
19.	24H1304	[1]	Washer	13/32" X 23/32" X 0.120"
20.	19H2676	[4]	Cap Screw	3/8" X 1", (USE WITH R62371)
20.	19H3467	[4]	Screw	5/16" X 1", (USE WITH T30720)
21.	19H3065	[1]	Cap Screw	3/8" X 2"
22.	15H584	[1]	Pipe Plug	1/2"
23.	AR41691	[1]	Seal Kit
24.	T30720	[1]	Hub	(SUB FOR R62371) (USE WITH T30721, NOT REUQIRED WITH T23628)
25.	AR101549	[1]	Seal Kit
26.	AR86636	[1]	Water Pump	(MARKED T29521) (SUB FOR AT27597, THIS APPLICATION) (SUB RE25043) (ALSO ORDER R55759 AND (3) 19H2545)
