Pos.	Part No	Qty	Parts name	Comments
1.	R27094	[1]	Drain Plug	(A)
2.	R26286	[1]	O-Ring	(A)
3.	R86192	[2]	O-Ring	(A) (SUB FOR U12331)
4.	R78823	[2]	Back-Up Ring	(A) (SUB FOR R35684, THIS APPLICATION)
5.	R48957	[1]	End	(A) END, (SUB FOR R46988)
6.	U10136	[2]	Snap Ring	(A)
7.	19H2676	[1]	Cap Screw	3/8" X 1"
8.	R35680	[1]	Seal	(A)
9.	R48952	[1]	Piston	(A) (SUB R57103, (2) A4728R, R27649 AND (2) L29015) (SUB FOR R44253)
10.	A4728R	[1]	O-Ring	(A)
11.	R47912	[1]	Cap	(A)
12.	R28084	[1]	Spring
13.	R47913	[1]	Orifice
14.	19H1356	[2]	Cap Screw	5/8" X 1-3/4", (WITH CANOPY)
14.	19H1833	[2]	Cap Screw	5/8" X 1-1/4", (WITHOUT CANOPY)
15.	12H294	[2]	Lock Washer	5/8"
16.	T25726	[1]	Bracket
17.	R41877	[1]	Guide	(A)
18.	R47086	[1]	Spring	(A)
19.	R47085	[1]	Valve	(A)
20.	R60038	[1]	Packing	(A) (SUB FOR R26760)
21.	R46986	[1]	Hydraulic Cylinder Barrel	(A)
22.	R35794	[1]	Clamp
23.	T22922	[1]	Support
24.	12H304	[5]	Lock Washer	3/8"
25.	14H812	[1]	Nut	3/8"
26.	19H2633	[2]	Cap Screw	3/8" X 1-1/2"
27.	19H2284	[2]	Cap Screw	3/8" X 7/8"
28.	R47087	[1]	Washer	(A)
29.	A4728R	[1]	O-Ring	(A)
30.	AR55711	[1]	Piston	PISTON WITH O-RINGS, (SUB FOR R49345) (SUB R57103, (2) A4728R, R27649 AND (2) L29015)
...	RE11966	[1]	Accumulator	(SUB FOR AR46054) (SUB RE29331) (ALSO ORDER R80752 ENGLISH LABEL, R80753 SPANISH LABEL, R80754 FRENCH LABEL AND R82337 GERMAN LABEL AS REQUIRED)
