Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Plug	( T33805 NO LONGER AVAILABLE) TACHOMETER
2.	37H24	[AR]	Screw	1/4" X 3/4", (3 USED WITH INSTRUMENT PANEL COVER, 5 USED WITHOUT INSTRUMENT PANEL COVER) (SUB FOR T23879, THIS APPLICATION)
3A.	AT34536	[1]	Instrument Panel	(SUB AT38591)
3A.	AT38591	[1]	Instrument Panel	(SUB AT56983 AND T16738)
3B.	AT56983	[1]	Instrument Panel
4.	BP13712	[3]	Nut	(SUB FOR W14541, THIS APPLICATION) (SUB FOR T33634)
5.	14H812	[6]	Nut	3/8"
6.	12H304	[6]	Lock Washer	3/8"
7.	T33635	[1]	Cover
8.	12H302	[6]	Lock Washer	1/4"
9.	19H1919	[6]	Cap Screw	1/4" X 5/8"
10.	24H1305	[4]	Washer	13/32" X 13/16" X 0.065"
11.	19H2284	[4]	Cap Screw	3/8" X 7/8"
12.	T33631	[1]	Support	R. REAR
13.	19H2021	[2]	Cap Screw	3/8" X 5/8"
14.	T31655	[1]	Foam Pad
15.	AT30730	[1]	Cowl
15.	........	[1]	Cowl	(WHEN AT53935 IS NO LONGER AVAILABLE,ORDER T56144 AND T31655)
15.	T56144	[1]	Cowl	(ALSO ORDER T31655)
16.	T31657	[1]	Bumper	(WITH CAB)
17.	T33632	[1]	Retainer	L. REAR
18.	T33617	[1]	Grommet
18.	T48195	[1]	Grommet
19.	T16738	[1]	Plug	HORN
20.	M2291T	[1]	Plug	CIGAR LIGHTER
21.	T51209	[1]	Isolator
22.	T16738	[1]	Plug	WITHOUT PARKING BRAKE INDICATOR LIGHT
