约翰迪尔零件查询410 - BACKHOE, LOADER COWL SUPPORT [02B08]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
314 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19H3483
|
[4] |
Cap Screw
|
|
| 2. |
24H1305
|
[2] |
Washer
|
|
| 3. |
T33629
|
[1] |
Bracket
|
|
| 4. |
12H304
|
[8] |
Lock Washer
|
|
| 5. |
14H812
|
[4] |
Nut
|
|
| 6. |
AT32747
|
[1] |
Support
|
|
| 6. |
AT48592
|
[1] |
Support
|
|
| 7. |
19H2633
|
[2] |
Cap Screw
|
|
| 7. |
19H2676
|
[2] |
Cap Screw
|
|
| 8. |
28H862
|
[2] |
Spacer
|
|
| 9. |
19H2676
|
[2] |
Cap Screw
|
|
| 10. |
T33630
|
[1] |
Clamp
|
|
| 11. |
24H1305
|
[2] |
Washer
|
|
| 12. |
........
|
[1] |
Bracket
|
|
| 13. |
........
|
[1] |
Barrier
|
|
| 14. |
T51210
|
[2] |
Isolator
|
|
| 15. |
T51212
|
[1] |
Barrier
|
|
