约翰迪尔零件查询410 - BACKHOE, LOADER RIGHT PLATFORM AND SUPPORT [02C04]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
465 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT37772
|
[1] |
Ramp
|
|
| 2. |
24H1307
|
[AR] |
Washer
|
|
| 3. |
12H304
|
[5] |
Lock Washer
|
|
| 4. |
19H2284
|
[5] |
Cap Screw
|
|
| 5. |
19H1914
|
[2] |
Cap Screw
|
|
| 6. |
12H302
|
[2] |
Lock Washer
|
|
| 7. |
T38942
|
[1] |
Platform
|
|
| 8. |
T38948
|
[1] |
Ramp
|
|
| 9. |
19H2716
|
[1] |
Cap Screw
|
|
| 10. |
12H236
|
[1] |
Lock Washer
|
|
| 11. |
T34019
|
[1] |
Support
|
|
| 12. |
14H786
|
[2] |
Nut
|
|
| 13. |
T45624
|
[1] |
Isolator
|
|
| 14. |
T45623
|
[1] |
Isolator
|
|
| 15. |
T45622
|
[1] |
Pad
|
|
