约翰迪尔零件查询410 - BACKHOE, LOADER ELECTRICAL WIRING SYSTEM [02D09]EPC John Deere online_约翰迪尔John Deere_工程机械

约翰迪尔零件查询410 - BACKHOE, LOADER ELECTRICAL WIRING SYSTEM [02D09]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 844 次

Pos.	Part No	Qty	Parts name	Comments
1.	12H295	[4]	Lock Washer	0.190"
2.	AT32859	[1]	Wiring Harness	(HORN BUTTON TO HORN AND CIRCUIT BREAKER)
3.	AT39043	[1]	High Note Horn	(SUB FOR R11276)
4.	AT25257	[1]	Switch	(SUB AT37390)
4.	AT37390	[1]	Switch
5.	14H631	[4]	Nut	0.190"
6.	AT85174	[1]	Switch	ENGINE OIL PRESSURE, (SUB FOR AR27977)
7.	R44302	[AR]	Tie Band
8.	AT14385	[1]	Electrical Coil
9.	AR38458	[1]	Alternator	35 AMPERE (MOTOROLA NO. A12NJD453) (WITHOUT CAB)
9.	TY24306	[1]	Alternator	(SUB FOR TY1427) (35 AMPERE) (MOTOROLA) (REMANUFACTURED)
9.	AR40420	[1]	Alternator	55 AMPERE (MOTOROLA NO. A12NJD604)
10.	AT20912	[1]	Sender
11.	14H605	[1]	Nut	0.164"
12.	12H315	[1]	Lock Washer	0.164"
13.	........	[1]	Starter Motor	(DELCO-REMY NO. 1998367) (SUB FOR AT25619, DELCO-REMY NO. 1107863 AND 1107871) (DIESEL) (SUB FOR RE19187, DELCO-REMY NO. 1998367) (SUB FOR RE42730) (SUB RE62916)
13.	TY6702	[1]	Starter Motor	(12-VOLT) (REMANUFACTURED) (DELCO-REMY) (INCLUDES SOLENOID COVER KIT) (SUB FOR TY6620)
13.	TY26037	[1]	Starter Motor	(REMANUFACTURED) (DELCO-REMY NO. 1108319) (GASOLINE) (SUB FOR AT18025, TY6706)
13.	SE501436	[1]	Starter Motor	(REMANUFACTURED FOR TY26037)
14.	T19935	[3]	Clamp
15.	AT32921	[1]	Wiring Harness	(DIESEL)
15.	AT54894	[1]	Wiring Harness	(DIESEL) (SUB AT73431 AND RE12169)
15.	AT73431	[1]	Wiring Harness	(DIESEL)
15.	AT32920	[1]	Wiring Harness	(GASOLINE)
15.	AT54893	[1]	Wiring Harness	(GASOLINE)
16.	AR28403	[1]	Circuit Breaker	(20 AMPERES)
17.	14H631	[4]	Nut	0.190"
18.	AN152652	[1]	Circuit Breaker	(SUB FOR AT29162) (40 AMPERES)
19.	........	[1]	Wiring Lead	(CIGAR LIGHTER TO CIRCUIT BREAKER) (MAKE FROM AR84066 WIRE REPAIR KIT) (SUB FOR AR30054)
19.	AT78634	[1]	Wiring Lead	(USE WITH AT78633)
20.	AT85153	[1]	Switch	SAFETY STARTER, (SUB FOR R36265, AR85323 AND AR89691) (USE WITH AU41461) (SUB RE38390)
20.	RE38390	[1]	Switch
21.	AR48643	[1]	Electrical Lighter	CIGAR
21.	AT78633	[1]	Housing	(ALSO ORDER AT78634) (SUB FOR AU41461, THIS APPLICATION)
22.	T16911	[1]	Shim	.38 MM (.015")
23.	T55501	[1]	Cap	HORN SWITCH
24.	T58440	[1]	Cap	ENGINE STARTING
25.	R39554	[2]	Switch	PUSH BUTTON, (SUB FOR AR47373)
