约翰迪尔零件查询410 - BACKHOE, LOADER REAR WINDSHIELD WIPER AND LEADS [02D12]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 987 次

Pos.	Part No	Qty	Parts name	Comments
1.	U41534	[8]	Clip
2.	37H32	[8]	Screw	0.190" X 3/8"
3.	........	[1]	Grommet	( M16663 NO LONGER AVAILABLE) (SUB FOR P40509)
4.	AT36933	[1]	Wiring Lead	FROM FUSE BLOCK ON PRESSURIZER
5.	H77698	[AR]	Tie Band	(SUB FOR AT30417 AND T44946)
6.	TY16299	[1]	Wiper Blade	(SUB FOR AT24505) (ALSO ORDER TY16324) (FOR FIRST TIME INSTALLATION)
7.	AT24504	[1]	Wiper Arm
8.	U46520	[1]	Gasket
9.	U46518	[1]	Spacer
10.	U46519	[1]	Nut
11.	21H1301	[1]	Screw	0.190" X 1/2"
12.	AT24502	[1]	Motor
13.	24H1283	[1]	Washer	7/32" X 1/2" X 0.049"
14.	12H246	[1]	Lock Washer	0.190"
15.	14H778	[1]	Nut	0.190"
16.	........	[1]	Holder	(AN112774 - NO LONGER AVAILABLE)
17.	AT28061	[1]	Fuse	5 AMP
18.	........	[1]	Wiring Lead	( AT36377 USE IF AVAILABLE) (TO BLOWER ON PRESSURIZER)
19.	AT36934	[1]	Wiring Lead	(WITHOUT PRESSURIZER)
19.	AT28061	[1]	Fuse	5 AMP
20.	AT36932	[1]	Wiring Lead	(ATTACHES TO WINDSHIELD MOTOR)
21.	T28585	[1]	Electrical Connector Assy
22.	TY16324	[1]	Kit	NOT ILLUSTRATED
