约翰迪尔零件查询410 - BACKHOE, LOADER CAB ELECTRICAL SYSTEM (SERIAL NO. 257255- ) [02D14]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 403 次

Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Wiring Lead	( AT36377 USE IF AVAILABLE)
2.	AM531T	[2]	Electrical Connector Assy
3.	........	[1]	Wiring Lead	1 194 MM (47") (MAKE FROM R32008 AND (2) R32026 FROM AR84006 WIRE REPAIR KIT)
4.	AT35243	[1]	Wiper Arm
5.	........	[1]	Wiring Lead	2 388 MM (94") (MAKE FROM R32008, R32026 AND R32019 FROM AR84006 WIRE REPAIR KIT)
6.	21H1317	[3]	Screw	0.190" X 5/8"
7.	........	[1]	Grommet	( M16663 NO LONGER AVAILABLE)
8.	........	[1]	Wiring Lead	178 MM (7") (MAKE FROM R32008, R32019 AND R32022 FROM AR84006 WIRE REPAIR KIT)
9.	12H246	[3]	Lock Washer	0.190"
10.	14H778	[3]	Nut	0.190"
11.	14H631	[2]	Nut	0.190"
12.	AN152652	[1]	Circuit Breaker	(SUB FOR AT29162)
13.	TY16302	[1]	Wiper Blade	(SUB FOR AT35244 OR AT115598 OR AT130075)
14.	T61876	[4]	Clip	(SUB FOR T37623)
15.	U46519	[1]	Nut
16.	U46518	[1]	Spacer
17.	U46520	[1]	Gasket
18.	24H1698	[1]	Washer	21/32" X 1-5/8" X 1/4"
19.	AT35245	[1]	Motor	(SUB AT74926) (ALSO ORDER AT74928)
19.	AT74926	[1]	Wiper Motor
20.	21H1148	[1]	Screw	0.190" X 3/4"
21.	AT36376	[1]	Wiring Lead
22.	AT28061	[1]	Fuse	5 AMP
23.	24H1283	[1]	Washer	7/32" X 1/2" X 0.049", (OUTSIDE CAB)
24.	24H1284	[1]	Washer	7/32" X 7/8" X 0.065", (INSIDE CAB)
25.	........	[1]	Toggle Switch	( AT36369 USE IF AVAILABLE)
26.	N114815	[1]	Lens
27.	........	[1]	Bulb	( AN111881 NO LONGER AVAILABLE)
28.	AT36370	[1]	Lamp
29.	H64612	[3]	Clip
30.	AR73144	[1]	Relay	(SUB FOR AT142305, ALSO ORDER (2) 14H785 AND (2) 12M7065) (SUB FOR AT74743)
31.	........	[1]	Wiring Lead	686 MM (27") (MAKE FROM TWO R32022 AND R32008 FROM AR84006 WIRE REPAIR KIT)
32.	AT54892	[2]	Clip	(SUB FOR R44302, THIS APPLICATION)
33.	........	[1]	Wiring Lead	1 016 MM (40") (MAKE FROM TWO R32018 AND R32007 FROM AR84006 WIRE REPAIR KIT)
34.	14H785	[4]	Nut	5/16"
34.	12M7065	[2]	Lock Washer	8 MM
...	AT42733	[1]	Cab	(INCLUDES ALL PARTS ON THIS PAGE AND PAGES 60-9, 60-10, 60-11, 65-5, AND ALL PARTS IDENTIFIED BY (A) ON PAGE 60-12 AND AT49552 AND AT49553) (SUB FOR AT35586)
