| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AR77325 | [1] | Socket | (USE WHEN AR77324 HAS BEEN INSTALLED AS A REPLACEMENT PART) |
| 2. | R30182 | [1] | Bezel | (HOBBS) |
| 2. | R31250 | [1] | Bezel | (GUIDE LAMP) |
| 3. | AR77324 | [1] | Lamp | 12-VOLT, (SUB FOR AR21737) (ALSO ORDER AD2062R AND AR77325) |
| 4. | AR86969 | [1] | Bulb | (SUB FOR AR21739) (USE WITH AR21737) |
| 4. | AD2062R | [1] | Bulb | (USE WHEN AR77324 HAS BEEN INSTALLED AS A REPLACEMENT PART) |
| 5. | R48663 | [1] | Washer | (SUB FOR R20758, THIS APPLICATION) |
| 6. | F2935R | [1] | Washer | |
| 7. | 24H1111 | [1] | Washer | 17/32" X 1-1/16" X 0.090" |
| 8. | 14H1040 | [1] | Nut | 1/2", (SUB FOR 14H809) |
| 9. | AT32866 | [1] | Floodlamp | FLOOD AND TAIL |
