约翰迪尔零件查询410 - BACKHOE, LOADER STARTING MOTOR COIL ASSEMBLY, HOUSING AND ARMATURE (DELCO-REMY NOS. 1107863 AND 1107871) (DIESEL) [0EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
217 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
R11243
|
[2] |
Cap Screw
|
|
| 2. |
R11238
|
[1] |
End Plate
|
|
| 3. |
R61932
|
[1] |
Bushing
|
|
| 4. |
37H79
|
[4] |
Screw
|
|
| 4. |
12M7084
|
[4] |
Lock Washer
|
|
| 5. |
R11239
|
[4] |
Brush
|
|
| 6. |
T738T
|
[2] |
Holder
|
|
| 7. |
AT514T
|
[2] |
Wiring Lead
|
|
| 8. |
T736T
|
[2] |
Pin Fastener
|
|
| 9. |
AT516T
|
[2] |
Kit
|
|
| 10. |
AT16290
|
[1] |
Field Winding Coil
|
|
| 11. |
T11680
|
[4] |
Shoe
|
|
| 12. |
........
|
[1] |
Housing
|
|
| 13. |
21H1280
|
[8] |
Screw
|
|
| 14. |
R11087
|
[1] |
Dowel Pin
|
|
| 15. |
R11095
|
[1] |
Washer
|
|
| 16. |
820149
|
[1] |
Bearing
|
|
| 17. |
R11236
|
[1] |
Grommet
|
|
| 18. |
AT16291
|
[1] |
Armature
|
|
| 19. |
R11096
|
[1] |
Washer
|
|
| 20. |
14H778
|
[4] |
Nut
|
|
| 21. |
12H246
|
[4] |
Lock Washer
|
|
| 22. |
21H1301
|
[4] |
Screw
|
|
| 23. |
T740T
|
[4] |
Spring
|
|
| 24. |
R11290
|
[2] |
Carbon Brush Holder
|
|
| 25. |
15H558
|
[1] |
Pipe Plug
|
|
| 26. |
H23193
|
[1] |
Felt
|
|
| 27. |
R61934
|
[AR] |
Wick
|
|
