约翰迪尔零件查询410 - BACKHOE, LOADER STARTING MOTOR COIL ASSEMBLY, HOUSING AND ARMATURE (DELCO-REMY NO. 1108319) (GASOLINE) [02E14]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
370 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T741T
|
[2] |
Bolt
|
|
| 2. |
AT517T
|
[1] |
Frame
|
|
| 3. |
T738T
|
[2] |
Holder
|
|
| 4. |
T735T
|
[4] |
Brush
|
|
| 5. |
37H2
|
[4] |
Screw
|
|
| 6. |
AT514T
|
[2] |
Wiring Lead
|
|
| 7. |
T736T
|
[2] |
Pin Fastener
|
|
| 8. |
21H1301
|
[4] |
Screw
|
|
| 9. |
12H246
|
[4] |
Lock Washer
|
|
| 10. |
14H778
|
[4] |
Nut
|
|
| 11. |
AT516T
|
[2] |
Kit
|
|
| 12. |
AR11105
|
[1] |
Field Winding Coil
|
|
| 13. |
R39857
|
[4] |
Shoe
|
|
| 14. |
AR11106
|
[1] |
Field Winding Coil
|
|
| 15. |
T743T
|
[4] |
Insulator
|
|
| 16. |
21H1280
|
[4] |
Screw
|
|
| 17. |
R11087
|
[1] |
Dowel Pin
|
|
| 18. |
........
|
[1] |
Housing
|
|
| 19. |
R11191
|
[1] |
Grommet
|
|
| 20. |
R11290
|
[2] |
Carbon Brush Holder
|
|
| 21. |
T740T
|
[2] |
Spring
|
|
| 22. |
R46191
|
[1] |
Washer
|
|
| 23. |
AT20663
|
[1] |
Armature
|
|
| 24. |
AR90826
|
[1] |
Field Winding Coil
|
|
| ... |
AT18025
|
[1] |
Starter Motor
|
|
