Pos.	Part No	Qty	Parts name	Comments
1.	........	[1]	Loader Bucket	0.76 M3 (1 YARD) ( AT33118, NO LONGER AVAILABLE)
1.	........	[1]	Loader Bucket	(A) 0.76 M3 (1 YARD) (INCLUDES ALL PARTS IDENTIFIED BY (A) ( AT39239 NO LONGER AVAILABLE)
2.	U11773	[2]	Hook
3A.	T34097	[2]	Pin	(BUCKET TO TILT LINK)
3B.	T40638	[2]	Pin	(A) (BUCKET TO TILT LINK)
4.	19H2458	[4]	Cap Screw	3/8" X 3"
5.	T11234	[4]	Lock Nut	3/8"
6A.	T31905	[2]	Pin	(BUCKET TO LIFT ARM)
6B.	AT86429	[2]	Pin Fastener	(A) (BUCKET TO LIFT ARM) (WITH GREASE FITTING) (SUB FOR T40637)
7.	H32811	[16]	Lock Nut	1/2" (7/8-YARD BUCKET) (SUB FOR U14502)
8.	19H2472	[6]	Cap Screw	1/2" X 1", (7/8-YARD BUCKET)
8.	19H2473	[2]	Cap Screw	1/2" X 1-3/4", (7/8-YARD BUCKET)
9.	10H1238	[8]	Bolt	NO. 3, 1/2" X 2-3/4" (7/8-YARD BUCKET)
10.	U13449	[8]	Tooth	(7/8-YARD BUCKET)
11.	T45155	[8]	Spring Pin	(7/8-YARD BUCKET)
12.	........	[8]	Shank	(7/8-YARD BUCKET) ( AU40885 NO LONGER AVAILABLE)
13.	T34095	[1]	Cutting Edge	(A) (7/8-YARD)
13.	........	[1]	Cutting Edge	( PBT34095 USE IF AVAILABLE) WITH HOLES - ALTERNATE FOR T34095
13.	T84180	[1]	Cutting Edge	AUXILIARY - FOR USE WITH PBT34095, (USE WITH (8) BP12214 AND (8) 10H1238)
13.	T34103	[1]	Cutting Edge	0.76 M3 (1 YARD BUCKET)
13.	PBT34103	[1]	Cutting Edge	(WITH HOLES) (ALTERNATE FOR T34103)
13.	T84194	[1]	Cutting Edge	(AUXILIARY) (FOR USE WITH PBT69229) (USE WITH BUCKET MARKED AT66306) (USE WITH (8) U44915, (8) 24M7241 AND (8) 09H1764)
14.	T162396	[2]	Lubrication Fitting	(A) 1/8" STRAIGHT, (SUB FOR JD7759 OR JD7798)
15.	U16068	[8]	Snap Ring	(A)
16.	U41344	[8]	Bucket Tooth Adapter
