| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AU40511 | [3] | Clamp | |
| 2. | AT44799 | [1] | Oil Line | UPPER, (SUB FOR AT37226) |
| 3. | AR21842 | [1] | Clamp | |
| 4. | AT44800 | [1] | Oil Line | LOWER, (SUB FOR AT37227) |
| 5. | 14H785 | [3] | Nut | 5/16" |
| 6. | 12H303 | [3] | Lock Washer | 5/16" |
| 7. | U13051 | [3] | Clamp | |
| 8. | AU40250 | [2] | Hydraulic Hose - Fabricate | 1 734 MM LONG (1/2" X 68-1/4") |
| 9. | AU11753 | [1] | Union Fitting | STRAIGHT |
| 10. | U11009 | [1] | Adapter Fitting |
