约翰迪尔零件查询410 - BACKHOE, LOADER LOADER SIDE FRAMES [02G03]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 437 次

Pos.	Part No	Qty	Parts name	Comments
1.	AT32901	[1]	Frame	L.H. (SUB AT73789) (ALSO ORDER T40636, T40639 AND (4) U16068)
1.	AT73789	[1]	Frame	L.H. (SUB FOR AT32901)
2.	U10457	[2]	Snap Ring
3.	24H1571	[2]	Washer	1-25/32" X 2-7/8" X 0.120"
4.	19H3404	[2]	Cap Screw	3/8" X 4"
5A.	T34097	[2]	Pin
5B.	T40636	[2]	Pin
6.	T11234	[2]	Lock Nut
7.	19H2994	[2]	Cap Screw	HS, SAE 8, 5/8" X 1-1/2"
8.	12H294	[2]	Lock Washer	5/8"
9.	U12948	[2]	Washer
10.	19H2726	[4]	Cap Screw	HS, SAE 8, 5/8" X 4"
11.	U40559	[2]	Support
12.	14H1039	[4]	Nut	5/8"
13.	AT32897	[1]	Frame	R.H. (SUB AT73787) (ALSO ORDER T40636, T40639 AND (4) U16068)
13.	AT73787	[1]	Frame	R.H. (SUB FOR AT32897)
14.	R27583	[4]	Grommet
15.	T35138	[2]	Clevis
16.	24H1272	[2]	Washer	9/16" X 1-1/4" X 1/4"
17.	14H1040	[2]	Nut	1/2", (SUB FOR 14H809)
18.	24M7241	[6]	Washer	17 X 34 X 4 MM, (SUB FOR T19584 AND T40728)
19.	19H2994	[2]	Cap Screw	HS, SAE 8, 5/8" X 1-1/2"
20.	19H1912	[2]	Cap Screw	3/8" X 3-1/2"
21.	T11234	[2]	Lock Nut
22.	U16068	[4]	Snap Ring
23.	14H836	[8]	Nut	7/8"
24.	12H245	[8]	Lock Washer	7/8"
25.	T33929	[8]	Spacer
26.	24H1433	[8]	Washer	29/32" X 2-1/4" X 1/4"
27.	08H4647	[8]	Cap Screw	7/8" X 13-1/2"
