约翰迪尔零件查询410 - BACKHOE, LOADER BUCKET SECTION OF LOADER CONTROL VALVE (WITHOUT DROTT 4-IN-1 BUCKET) [02G11]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 407 次

Pos.	Part No	Qty	Parts name	Comments
1.	32240	[2]	O-Ring	(A)
2.	AU40752	[1]	Pressure Relief Valve	190 BAR (2750 PSI)
3.	U40727	[2]	Back-Up Ring	(A)
4.	P47908	[2]	O-Ring	(A)
5.	........	[1]	Housing	(SUB AT29939)
6.	AU40528	[1]	Pressure Relief Valve	103 BAR (1500 PSI)
7.	U42834	[1]	Boot
8.	21H1352	[2]	Screw	1/4" X 3/8"
9.	U42827	[1]	Retainer
10.	U42835	[1]	Washer
11.	T57246	[1]	O-Ring	(A) (SUB FOR T30946, THIS APPLICATION)
12.	U41172	[1]	Plunger
13.	N85304	[1]	Spring
14.	R394R	[1]	O-Ring	(A)
15.	AN85149	[1]	Fitting
16.	T13119	[1]	O-Ring	(A) (SUB FOR T57245) (SUB FOR W27980, THIS APPLICATION)
17.	U41169	[1]	Bushing
18.	U42833	[1]	Clevis
19.	P46051	[2]	O-Ring	(A)
20.	U41168	[1]	Check Valve
21.	........	[1]	Spool	(SUB AT29939)
22.	U41162	[1]	Plug
23.	H26239	[1]	Washer
24.	T30941	[1]	Spring
25.	H26237	[1]	Washer
26.	H26238	[1]	Guide
27.	U41299	[1]	Screw
28.	AT29940	[1]	Cap
29.	U41170	[1]	Spring
30.	AT29939	[1]	Spool Valve
...	AT29941	[1]	Seal Kit	SEAL REPAIR
