| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | U42742 | [1] | Cutting Edge | R.H., 13 MM X 76 MM X 807 MM (1/2" X 3" X 31-3/4") (USE WITH AT34975, AT34982, AT34976, AT34984, AT34977 AND AT34985) (FOR 457 MM (18"), 610 MM (24") AND 762 MM (30") BUCKETS) |
| 1. | T38857 | [1] | Cutting Edge | R.H., 13 MM X 127 MM X 876 MM (1/2" X 5" X 34-1/2") (USE WITH AT37722, AT37723 AND AT37724) (FOR 457 MM (18"), 610 MM (24") AND 762 MM (30") BUCKETS) |
| 1. | U42744 | [1] | Cutting Edge | R.H., 13 MM X 102 MM X 699 MM (1/2" X 4" X 27-1/2") (USE WITH AT34978 AND AT34986) (FOR 914 MM (36") BUCKETS) |
| 1. | T38870 | [1] | Cutting Edge | R.H., 13 MM X 127 MM X 762 MM (1/2" X 5" X 30") (USE WITH AT37725) (FOR 914 MM (36") BUCKETS) |
| 2. | U42753 | [1] | Cutting Edge | FRONT, 16 MM X 152 MM X 425 MM (5/8" X 6" X 16-3/4") (USE WITH AT34975 AND AT34982) (FOR 457 MM (18") BUCKET) |
| 2. | T38856 | [1] | Cutting Edge | FRONT, 22 MM X 152 MM X 425 MM (7/8" X 6" X 16-3/4") (USE WITH AT37722) (FOR 457 MM (18") BUCKET) |
| 2. | U42752 | [1] | Cutting Edge | FRONT, (CURVED END) 16 MM X 152 MM X 578 MM (5/8" X 6" X 22-3/4") (USE WITH AT34976 AND AT34984) (FOR 610 MM (24") BUCKET) |
| 2. | T38862 | [1] | Cutting Edge | FRONT, (STRAIGHT END) 22 MM X 152 MM X 578 MM (7/8" X 6" X 22-3/4") (USE WITH AT37723) (FOR 610 MM (24") BUCKETS) |
| 2. | U42754 | [1] | Cutting Edge | FRONT, 16 MM X 152 MM X 730 MM (5/8" X 6" X 28-3/4") (USE WITH AT34977 AND AT34985) (FOR 762 MM (30") BUCKETS) |
| 2. | T38865 | [1] | Cutting Edge | FRONT, 22 MM X 152 MM X 730 MM (7/8" X 6" X 28-3/4") (USE WITH AT37724) (FOR 762 MM (30") BUCKETS) |
| 2. | U42755 | [1] | Cutting Edge | FRONT, 16 MM X 152 MM X 883 MM (5/8" X 6" X 34-3/4") (USE WITH AT34978 AND AT34986) (FOR 914 MM (36") BUCKETS) (CURVED END) |
| 2. | T38869 | [1] | Cutting Edge | FRONT, 22 MM X 152 MM X 883 MM (7/8" X 6" X 34-3/4") (USE WITH AT37725) (FOR 914 MM (36") BUCKETS) |
| 3. | T36126 | [AR] | Shank | (SUB T417X230) (FOUR USED WITH AT34975, AT34982, AT34976 AND AT34984, FIVE USED WITH AT34977 AND AT34985, SIX USED WITH AT34978 AND AT34986) |
| 3. | T417X230 | [AR] | Bucket Tooth Adapter | |
| 3. | U43792 | [AR] | Bucket Tooth Adapter | (SUB FOR U42750) (4 U/W AT37722 AND AT37723, 5 U/W AT37724, 6 U/W AT37725) |
| 4. | U42751 | [AR] | Point | (4 U/W 457MM-18" AND 610MM-24" BUCKETS, 5 U/W 762MM-30" BUCKET, 6 U/W 914MM-36" BUCKET) |
| 4. | T56524 | [AR] | Point | (4 U/W 457MM-18" AND 610MM-24" BUCKETS, 5 U/W 762MM-30" BUCKET, 6 U/W 914MM-36" BUCKET) (FOR USE WITH HEAVY-DUTY APPLICATION) |
| 5. | U42743 | [1] | Cutting Edge | SIDE, L.H., 13MM X 76MM X 807MM (1/2" X 3" X 31-3/4") (FOR 457MM-18", 610MM -24" AND 762MM-30" BUCKETS) (USE WITH AT34975, AT34982, AT34976, AT34984, AT34977 AND AT34985) |
| 5. | T38858 | [1] | Cutting Edge | SIDE, L.H., 13 MM X 127 MM X 876 MM (1/2" X 5" X 34-1/2") (FOR 457 MM (18"), 610 MM (24") AND 762 MM (30") BUCKETS) (USE WITH AT37722, AT37723 AND AT37724) |
| 5. | U42745 | [1] | Cutting Edge | SIDE, L.H., 13 MM X 102 MM X 699 MM (1/2" X 4" X 27-1/2") (FOR 914 MM (36") BUCKET) (USE WITH AT34978 AND AT34986) |
| 5. | T38871 | [1] | Cutting Edge | SIDE, L.H., 13 MM X 127 MM X 762 MM (1/2" X 5" X 30") (FOR 914 MM (36") BUCKET) (USE WITH AT37725) |
| 6. | ........ | [1] | Backhoe Bucket | 457 MM (18") ( AT37722, USE IF AVAILABLE) (SUB AT114260) (SUB FOR AT34975 AND AT34982) |
| 6. | ........ | [1] | Backhoe Bucket | 610 MM (24") ( AT37723, USE IF AVAILABLE) (SUB AT114257) (SUB FOR AT34976 AND AT34984) |
| 6. | ........ | [1] | Backhoe Bucket | 762 MM (30") ( AT37724, USE IF AVAILABLE) (SUB AT114262) (SUB FOR AT34977 AND AT34985) |
| 6. | ........ | [1] | Backhoe Bucket | 914 MM (36") ( AT37725, USE IF AVAILABLE) (SUB AT114256) (SUB FOR AT34978 AND AT34986) |
| 7. | AU41835 | [1] | Plate | L.H. (SUB AT36086, CONSISTS OF L.H. AND R.H. PLATE) |
| 8. | T105987 | [2] | Bushing | (SUB FOR U42736) |
| 9. | T105988 | [4] | Bushing | (SUB FOR U42739) |
| 10. | 28H2196 | [1] | Spacer | 1-1/2" X 6" |
| 11. | U11650 | [2] | Washer | |
| 12. | 11H221 | [4] | Cotter Pin | 3/8" X 2-1/2" |
| 13A. | AU42333 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) |
| 13B. | T59450 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) |
| 13C. | AU42333 | [1] | Pin Fastener | (SUB (2) U11650, (2) 11H221 AND T125926) |
| 13C. | T125926 | [1] | Pin Fastener | (DOES NOT INCLUDE WASHERS OR COTTER PINS) |
| 14. | AU41834 | [1] | Plate | R.H. (SUB AT36086, CONSISTS OF L.H. AND R.H. PLATE) |
| 15. | U11649 | [2] | Washer | |
| 16A. | AU42334 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) |
| 16B. | T59451 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) |
| 16C. | AU42334 | [1] | Pin Fastener | (SUB (2) U11649, (2) 11H221 AND T125931) |
| 16C. | T125931 | [1] | Pin Fastener | (DOES NOT INCLUDE WASHERS OR COTTER PINS) |
| 17. | T40910 | [AR] | Pin | (4 USED WITH 457 MM (18") AND 610 MM (24") BUCKETS, 5 USED WITH 762 MM (30") BUCKET, 6 USED WITH 914 MM (36") BUCKET) (SUB FOR U13927) |
| 18. | AT34983 | [AR] | Tooth | (4 USED WITH AT34975, AT34982, AT34976, AND AT34984, 5 USED WITH AT34977 AND AT34985, 6 USED WITH AT34978 AND AT34986) (USE WITH 16 MM (5/8") CUTTING EDGE) |
| 18. | ........ | [AR] | Tooth | (4 USED WITH AT37722 AND AT37723, 5 USED WITH AT37724, 6 USED WITH AT37725) (USE WITH 22 MM (7/8") CUTTING EDGE) ( AU41838 - NO LONGER AVAILABLE) (SUB T40910, U43792 AND U42751) |
| 19. | AT36086 | [1] | Plate | |
| 20. | T59452 | [2] | Snap Ring | |
| 21. | T59445 | [2] | Snap Ring |
