约翰迪尔零件查询410 - BACKHOE, LOADER BACKHOE EXTENDIBLE DIPPERSTICK HOUSING (SERIAL NO. -372783) [02J11]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
865 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
H35226
|
[2] |
Snap Ring
|
|
| 2. |
19H3550
|
[1] |
Cap Screw
|
|
| 3. |
T51852
|
[2] |
Clip
|
|
| 4. |
T51851
|
[1] |
Pin Fastener
|
|
| 5. |
AT50195
|
[1] |
Housing
|
|
| 6. |
T51847
|
[10] |
Screw
|
|
| 7. |
T72858
|
[2] |
Strap
|
|
| 8. |
........
|
[1] |
Plate
|
|
| 9. |
12H301
|
[3] |
Lock Washer
|
|
| 10. |
14H1040
|
[3] |
Nut
|
|
| 11. |
19H1820
|
[2] |
Cap Screw
|
|
| 12. |
T113347
|
[1] |
Pin
|
|
| 13. |
T30997
|
[1] |
Pin
|
|
| 14. |
AT50197
|
[1] |
Housing
|
|
