约翰迪尔零件查询410 - BACKHOE, LOADER EXTENDIBLE DIPPERSTICK CYLINDER [02J21]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 985 次

Pos.	Part No	Qty	Parts name	Comments
1.	T51861	[1]	Clevis	(SUB FOR T51897)
2.	34H288	[1]	Spring Pin	(A) (B) 3/16" X 1-3/4", (SUB FOR T51862)
3.	........	[1]	Seal	(A) (B) ( T51863 NO LONGER AVAILABLE)
4.	T51864	[1]	Ring
5.	T51865	[1]	Bushing	(B)
6.	........	[1]	Seal	(A) (B) ( T51866 NO LONGER AVAILABLE)
7.	T51867	[1]	Guide
8.	R81194	[1]	Back-Up Ring	(A) (B) (SUB FOR U13461, THIS APPLICATION)
9.	F1870R	[2]	O-Ring	(A) (B) (SUB FOR T51869)
10.	T51898	[1]	Rod
11.	T51871	[1]	Torsional Damper
12.	A3606R	[1]	O-Ring	(A) (B) (SUB FOR T51872)
13.	T51873	[1]	Spring
14.	T51874	[4]	Snap Ring	(B)
15.	T51875	[1]	Piston
16.	L2104N	[1]	O-Ring	(A) (B) (SUB FOR T51876)
17.	P48347	[1]	O-Ring	(A) (B) (SUB FOR T51877)
18.	P45231	[1]	Lock Nut	(A) (B) (SUB FOR T51878)
19.	T51899	[1]	Tube
20.	AT50200	[1]	Housing
21.	........	[1]	Set Screw	( T51880 NO LONGER AVAILABLE)
...	AT50199	[1]	Cylinder
...	AT50213	[1]	Seal Kit	SOFT SEAL REPAIR
...	AT50214	[1]	Kit	MAJOR REPAIR
