约翰迪尔零件查询410B - BACKHOE, LOADER HOOD [02G14]EPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
209 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
AT74734
|
[1] |
Door
|
|
| 2. |
AT44188
|
[16] |
Rivet
|
|
| 3. |
T68131
|
[1] |
Hinge
|
|
| 4. |
AT74620
|
[1] |
Hood
|
|
| 4. |
AT74613
|
[1] |
Hood
|
|
| 5. |
AT74617
|
[1] |
Rod
|
|
| 6. |
14M7274
|
[2] |
Nut
|
|
| 7. |
19M7658
|
[2] |
Cap Screw
|
|
| 8. |
14M7167
|
[4] |
Lock Nut
|
|
| 9. |
24H1219
|
[4] |
Washer
|
|
| 10. |
19M7804
|
[4] |
Screw
|
|
| 11. |
19M7775
|
[2] |
Screw
|
|
| 12. |
T68133
|
[1] |
Plate
|
|
| 13. |
14M7303
|
[2] |
Flange Nut
|
|
| 14. |
24H1287
|
[2] |
Washer
|
|
| 15. |
T26072
|
[1] |
Spring
|
|
| 16. |
U42544
|
[1] |
Clamp
|
|
| 17. |
19M7867
|
[2] |
Screw
|
|
| 18. |
AT74617
|
[1] |
Rod
|
|
