| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7402 | [8] | Cap Screw | M10 X 25 |
| 2. | 24H1305 | [8] | Washer | 13/32" X 13/16" X 0.065" |
| 3. | T76373 | [2] | Bar | |
| 4. | AT74610 | [1] | Frame | |
| 5. | W14783 | [8] | Washer | |
| 6. | 19M7824 | [4] | Screw | M16 X 60 |
| 7. | T68060 | [1] | Grille | |
| 8. | T55841 | [4] | Strap | |
| 9. | 19M7166 | [4] | Cap Screw | M10 X 20 |
| 10. | 14M7291 | [4] | Flange Nut | M16 |
| 11. | T68051 | [2] | Strap | (USE WITH AIR CONDITIONER) |
