约翰迪尔零件查询410C - BACKHOE, LOADER POWER STEERING VALVE [02G06]EPC John Deere online

广数供应链运营团队, 16 02月, 2025，浏览： 210 次

Pos.	Part No	Qty	Parts name	Comments
1.	C15104	[1]	Seal	(K)
2.	T54324	[1]	Snap Ring
3.	T54323	[1]	Isolator
4.	C15107	[1]	O-Ring	(K)
5.	B3690R	[1]	O-Ring	(K)
6.	T41836	[2]	Thrust Bearing Race
7.	JD8856	[1]	Needle Bearing
8.	........	[6]	Spring	(K1) ( T37261 - NO LONGER AVAILABLE)
9.	........	[1]	Housing	(SUB AT198741)
10.	M4124T	[1]	Dowel Pin
11.	........	[1]	Spool	(SUB AT198741)
12.	........	[1]	Sleeve	(SUB AT198741)
13.	........	[1]	Housing	(SUB AT198741)
14.	T64311	[1]	Retainer
15.	R26552	[1]	Ball
16.	R10093	[1]	O-Ring	(K)
17.	T64312	[1]	Seat
18.	A3917R	[1]	O-Ring	(K)
19.	T64313	[1]	Set Screw
20.	T37253	[1]	Drive
21.	T64318	[1]	Spacer
22.	........	[3]		(K) (SUB T152288) ( T70321 NLA)
23.	T64310	[1]	Washer
24.	AT61111	[1]	Rotor
25.	T64308	[1]	Cap
26.	T64317	[7]	Screw
26.	........	[7]	Washer	(K) (NOT ILLUSTRATED) ( T34972 USE IF AVAILABLE)
27.	T77345	[2]	Spacer	(K1)
28.	........	[1]	Valve	(SUB FOR AT101661, THIS APPLICATION) (SUB FOR AT107619) ( AT168630 N0 L0NGER AVAILABLE)(SUB. AT198741
