| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | AT101244 | [1] | Strap | |
| 2. | 14M7303 | [2] | Flange Nut | M6 |
| 3. | 14M7274 | [4] | Nut | M10 |
| 4. | 24M7296 | [8] | Washer | 10.500 X 30 X 2.500 MM |
| 5. | T69615 | [1] | Angle | |
| 6. | 19M7402 | [4] | Cap Screw | M10 X 25 |
| 7. | T69616 | [1] | Angle | |
| 8. | AT101243 | [1] | Support | |
| 9. | 19M7865 | [2] | Screw | M8 X 16 |
| 10. | AT101277 | [1] | Cover | |
| 11. | 24H1287 | [1] | Washer | 9/32" X 5/8" X 0.065" |
| 12. | 21M7277 | [1] | Screw | M6 X 25 |
| 13. | 19M7862 | [2] | Screw | M6 X 20 |
