| Pos. | Part No | Qty | Parts name | Comments |
|---|---|---|---|---|
| 1. | 19M7949 | [1] | Cap Screw | M12 X 100 |
| 2A. | T75383 | [1] | Pin Fastener | |
| 2B. | AT164442 | [1] | Pin | |
| 3. | 14M7319 | [1] | Lock Nut | M12 |
| 4. | 28H3365 | [1] | Washer | 0.742" X 1.050" X 5/16" |
| 4. | T18145 | [1] | Bushing | 16.281 X 25.400 X 13.500 MM (41/64" X 1" X 17/32") (SUB FOR 28H1885, THIS APPLICATION) |
| 5. | T119912 | [1] | Washer | |
| 5. | 24H1106 | [1] | Washer | 11/16" X 1-3/4" X 0.134" |
| 6. | 19M8035 | [1] | Cap Screw | M16 X 35 |
| 6. | 19M7488 | [1] | Cap Screw | M16 X 40 |
