约翰迪尔零件查询410G - BACKHOE, LOADER Planetary Pinion CarrierEPC John Deere online
广数供应链运营团队, 16 02月, 2025，浏览：
659 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
T166084
|
[1] |
Planet Pinion Carrier
|
|
| 2. |
........
|
[1] |
Housing
|
|
| 3. |
T183922
|
[6] |
Washer
|
|
| 4. |
AT179538
|
[3] |
Tapered Roller Bearing
|
|
| 5. |
T183923
|
[6] |
Snap Ring
|
|
| 6. |
T183921
|
[3] |
Planet Pinion
|
|
| 7. |
L110729
|
[3] |
Snap Ring
|
|
| 8. |
T159518
|
[1] |
Thrust Washer
|
|
| 9. |
T159525
|
[1] |
Shim
|
|
| 9. |
T159523
|
[1] |
Shim
|
|
| 9. |
T159522
|
[1] |
Shim
|
|
| 9. |
T161249
|
[1] |
Shim
|
|
| 9. |
T161248
|
[1] |
Shim
|
|
| 10. |
T159519
|
[1] |
Snap Ring
|
|
| 11. |
T166085
|
[1] |
Plate
|
|
| 12. |
T154952
|
[1] |
Shaft
|
|
| 13. |
T164844
|
[2] |
Groove Pin
|
|
