久保田零件查询050000 STEP BODYEPC Kubota online
广数供应链运营团队, 16 02月, 2025，浏览：
971 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
3526029180
|
[1] |
GUIDE AUX S-CHANGE L
|
0.3850(lbs); 0.175
|
| 002. |
0112050816
|
[2] |
BOLT
|
0.0000(lbs); 0.000
|
| 003. |
0211450080
|
[2] |
NUT
|
0.0110(lbs); 0.005
|
| 004. |
0401350080
|
[1] |
WASHER PLAIN
|
0.0066(lbs); 0.003
|
| 005. |
3520029140
|
[1] |
FENDER RH
|
1.2100(lbs); 0.550
|
| 005. |
3526029140
|
[1] |
FENDER RH
|
1.5840(lbs); 0.720
|
| 006. |
3520029160
|
[1] |
FENDER LH
|
1.1660(lbs); 0.530
|
| 006. |
3526029160
|
[1] |
FENDER LH
|
0.8910(lbs); 0.405
|
| 007. |
3526029040
|
[1] |
BOLT RH
|
2.0900(lbs); 0.950
|
| 008. |
3526029060
|
[1] |
BOLT LH
|
2.1780(lbs); 0.990
|
| 009. |
0217450120
|
[1] |
NUT
|
0.0220(lbs); 0.010
|
| 010. |
0451250120
|
[1] |
WASHER SPRING
|
0.0066(lbs); 0.003
|
| 011. |
0112050825
|
[4] |
BOLT
|
0.0000(lbs); 0.000
|
| 011. |
0112050820
|
[4] |
BOLT
|
0.0000(lbs); 0.000
|
| 012. |
0401550080
|
[20] |
WASHER PLAIN
|
0.0220(lbs); 0.010
|
| 013. |
0300450820
|
[8] |
SCREW WITH WASHER
|
0.0242(lbs); 0.011
|
| 014. |
0211450080
|
[12] |
NUT
|
0.0110(lbs); 0.005
|
| 015. |
3520029210
|
[2] |
SPACER FENDER
|
1.7600(lbs); 0.800
|
| 016. |
3520029010
|
[4] |
DAMPER
|
0.2090(lbs); 0.095
|
| 017. |
0401550080
|
[8] |
WASHER SPRING
|
0.0220(lbs); 0.010
|
| 018. |
3526029020
|
[1] |
LINK FENDER SUPPORT
|
3.4760(lbs); 1.580
|
| 018. |
3526029023
|
[1] |
LINK FENDER SUPPORT
|
5.2360(lbs); 2.380
|
| 019. |
0113051025
|
[4] |
BOLT
|
0.0000(lbs); 0.000
|
| 019. |
0113051020
|
[4] |
BOLT
|
0.0000(lbs); 0.000
|
| 020. |
0401350100
|
[4] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 020. |
0401550100
|
[4] |
WASHER PLAIN
|
0.0396(lbs); 0.018
|
| 021. |
3415018180
|
[8] |
CUSHION
|
0.0066(lbs); 0.003
|
| 022. |
3526029030
|
[4] |
U NUT
|
0.0220(lbs); 0.010
|
| 023. |
3526029050
|
[2] |
SUPPORT
|
0.2200(lbs); 0.100
|
| 024. |
3526029900
|
[1] |
ASSY STEP RH
|
0.0000(lbs); 0.000
|
| 024. |
3526029902
|
[1] |
ASSY STEP RH
|
7.0400(lbs); 3.200
|
| 025. |
9999999999
|
[1] |
BLANK
|
0.0000(lbs); 0.000
|
| 026. |
3526029900
|
[1] |
SHAFT ACCEL PEDAL
|
0.0000(lbs); 0.000
|
| 027. |
9999999999
|
[1] |
BLANK
|
0.0000(lbs); 0.000
|
| 028. |
3715017530
|
[1] |
SPRING
|
0.0220(lbs); 0.010
|
| 029. |
3526029920
|
[1] |
STEP LH
|
0.0000(lbs); 0.000
|
| 029. |
3526029924
|
[1] |
STEP LH
|
6.2700(lbs); 2.850
|
| 030. |
0113351016
|
[6] |
BOLT
|
0.0374(lbs); 0.017
|
| 031. |
3526029930
|
[1] |
STEP SUPPORT RH
|
0.5720(lbs); 0.260
|
| 032. |
3526029940
|
[1] |
STEP SUPPORT LH
|
0.5610(lbs); 0.255
|
| 033. |
0112350816
|
[2] |
BOLT
|
0.0242(lbs); 0.011
|
| 034. |
3526029950
|
[2] |
CUSHION
|
0.0440(lbs); 0.020
|
| 035. |
0117351060
|
[2] |
BOLT
|
0.0836(lbs); 0.038
|
| 036. |
0211850100
|
[2] |
NUT
|
0.0110(lbs); 0.005
|
| 037. |
0401350100
|
[4] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 038. |
6659141550
|
[2] |
COLLAR
|
0.0440(lbs); 0.020
|
| 039. |
3415029370
|
[2] |
CLAMP CORD
|
0.0110(lbs); 0.005
|
