| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 001. |
3520023300
|
[1] |
GUIDE SHIFT ROD
|
1.0340(lbs); 0.470
|
| 002. |
0113351030
|
[1] |
BOLT
|
0.0550(lbs); 0.025
|
| 003. |
0113351065
|
[1] |
BOLT
|
0.0946(lbs); 0.043
|
| 004. |
3520023340
|
[1] |
PLATE
|
0.0330(lbs); 0.015
|
| 005. |
0105050512
|
[2] |
BOLT
|
0.0066(lbs); 0.003
|
| 005. |
0105050510
|
[2] |
BOLT
|
0.0066(lbs); 0.003
|
| 006. |
0451250050
|
[2] |
WASHER SPRING
|
0.0022(lbs); 0.001
|
| 007. |
0401350050
|
[4] |
WASHER PLAIN
|
0.0022(lbs); 0.001
|
| 008. |
3715024610
|
[1] |
FORK SHIFT
|
0.4620(lbs); 0.210
|
| 009. |
3520024630
|
[1] |
SHAFT FORK
|
0.3520(lbs); 0.160
|
| 010. |
3415024680
|
[1] |
SCREW SET
|
0.0330(lbs); 0.015
|
| 011. |
0471700800
|
[1] |
WASHER SEAL
|
0.0022(lbs); 0.001
|
| 012. |
0481100090
|
[1] |
O RING
|
0.0022(lbs); 0.001
|
| 013. |
0771501605
|
[1] |
BALL
|
0.0066(lbs); 0.003
|
| 014. |
6223118530
|
[1] |
SPRING
|
0.0440(lbs); 0.020
|
| 015. |
3520024710
|
[1] |
LEVER PTO
|
0.4400(lbs); 0.200
|
| 016. |
0541100425
|
[1] |
PIN SPRING
|
0.0022(lbs); 0.001
|
| 017. |
3415024690
|
[1] |
PIN
|
0.0440(lbs); 0.020
|
| 018. |
3520024850
|
[1] |
LEVER PTO
|
0.4840(lbs); 0.220
|
| 019. |
3526024900
|
[1] |
LEVER CHECK
|
0.2090(lbs); 0.095
|
| 020. |
0117051020
|
[1] |
BOLT
|
0.0000(lbs); 0.000
|
| 021. |
3526024910
|
[1] |
COLLAR
|
0.0066(lbs); 0.003
|
| 022. |
0401350100
|
[2] |
WASHER PLAIN
|
0.0088(lbs); 0.004
|
| 023. |
3526024920
|
[1] |
HOOK
|
0.0110(lbs); 0.005
|
| 024. |
3437015770
|
[1] |
SPRING
|
0.0088(lbs); 0.004
|
| 025. |
3520024950
|
[1] |
LABEL PTO
|
0.0022(lbs); 0.001
|
