卡特零件查询（740） 205-5115: LINES GP-EJECTOR
广数供应链运营团队, 16 02月, 2025，浏览：
838 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 194-1559 | [1] | TUBE AS | |
| 2. | 194-1560 | [1] | TUBE AS | |
| 3. | 197-6651 | [1] | SHIELD AS | |
| 4. | 205-6222I | [1] | HOSE AS | |
| 5. | 205-6223I | [1] | HOSE AS | |
| 6. | 128-4194I | [1] | HOSE AS | |
| 7. | 294-9586 | [1] | TUBE AS | |
| 8. | 294-9587 | [1] | TUBE AS | |
| 9. | 205-9916 | [1] | TUBE AS | |
| 10. | 205-9917 | [1] | TUBE AS | |
| 11. | 207-2675Y | [1] | MANIFOLD & MTG GP-EJECTOR | |
| 12. | 1P-3704 | [1] | SEAL-RECTANGULAR | |
| 13. | 1P-4578 | [2] | FLANGE-HALF | |
| 14. | 1P-5761 | [2] | FLANGE-HALF | |
| 15. | 4J-0520 | [1] | SEAL-O-RING | |
| 16. | 4J-0522 | [1] | SEAL-O-RING | |
| 17. | 5K-9090 | [1] | SEAL-O-RING | |
| 18. | 5P-1076 | [12] | WASHER-HARD(13.5X30X4-MM THK) | |
| 19. | 6B-2882 | [5] | SPACER(0.406X0.75X0.312-IN THK) | |
| 20. | 6V-3265 | [4] | CLIP | |
| 21. | 6V-8397 | [4] | SEAL-O-RING | |
| 22. | 8C-3206 | [2] | FLANGE-HALF | |
| 23. | 8T-1887 | [2] | CLIP(SLOT) | |
| 24. | 8T-1888 | [2] | CLIP(TAB) | |
| 25. | 8T-1889 | [3] | CLIP(SLOT) | |
| 26. | 8T-1890 | [3] | CLIP(TAB) | |
| 27. | 8T-4121 | [20] | WASHER-HARD(11X21X2.5-MM THK) | |
| 28. | 8T-4133M | [4] | NUT(M10X1.5-THD) | |
| 29. | 8T-4182M | [7] | BOLT(M10X1.5X45-MM) | |
| 30. | 8T-4186M | [4] | BOLT(M10X1.5X40-MM) | |
| 31. | 8T-4192M | [4] | BOLT(M12X1.75X25-MM) | |
| 32. | 8T-4196M | [5] | BOLT(M10X1.5X35-MM) | |
| 33. | 8T-4244M | [4] | NUT(M12X1.75-THD) | |
| 34. | 8T-4956M | [4] | BOLT(M12X1.75X35-MM) | |
| 35. | 8W-8909 | [2] | SLEEVE | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
