卡特零件查询（AP-1055D） 245-1145: PUMP GP-GEAR
广数供应链运营团队, 16 02月, 2025，浏览：
925 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | HZ | [4] | SEAL-O-RING |
| 2. | 4B-8353 | [4] | PIN | |
| 3. | 5P-8244 | [16] | WASHER-HARD(12X22.5X2.5-MM THK) | |
| 4. | 5B-3254 | [16] | NUT-JAM(7/16-20-THD) | |
| 5. | 102-8073 | [1] | NUT-TRACK | |
| 6. | 155-9133 | [1] | KEY | |
| 7. | 6V-7424 | [1] | RING-RETAINING | |
| 8. | 139-6098H | [1] | SEAL-LIP TYPE | |
| 9. | HZ | [2] | SEAL |
| 10. | HZ | [2] | RING-BACKUP |
| 11. | HZ | [1] | SEAL-O-RING |
| 12. | HZ | [1] | SEAL-O-RING |
| | | | |
| | | | AVAILABLE REPAIR KIT(S): |
| | 259-2604H | [1] | KIT-SEAL(HYDRAULIC FAN PUMP) | |
| | H | | KIT MARKED H SERVICES PART(S) MARKED H |
| | Z | | NOT SERVICED SEPARATELY |
