卡特零件查询（AP-1055D） 230-9379: PUMP GP-PISTON
广数供应链运营团队, 16 02月, 2025，浏览：
651 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 7R-3825 | [1] | KIT-RELIEF VALVE | |
| | | | (INCLUDES NUT, O-RING SEAL, SPRING, POPPET CHARGE & PLUG AS) |
| 2. | 2M-9780 | [1] | SEAL-O-RING | |
| 3. | 108-3003 | [1] | GASKET-END CAP | |
| 4. | 6V-5215M | [6] | BOLT(M8X1.25X16-MM) | |
| 5. | 1G-9327 | [2] | KIT-SLEEVE | |
| 6. | 1G-9191 | [2] | SEAL-O-RING | |
| 7. | 1G-9192 | [2] | SEAL-O-RING | |
| 8. | 276-6041Y | [1] | VALVE GP-PUMP CONTROL | |
| 9. | 8T-0269M | [3] | BOLT-SOCKET HEAD(M6X1X20-MM) | |
| 10. | 275-6466 | [1] | PLATE-RETAINING | |
| 11. | 153-4918 | [1] | KIT-SEAL | |
| | | | (INCLUDES LIP SEAL, CARRIER SEAL & O-RING SEAL) |
| 12. | 111-6216 | [1] | KIT-SEAL | |
| 13. | 1G-9188 | [1] | SEAL-O-RING | |
| 14. | 192-2107 | [1] | KIT-PISTON | |
| | | | (INCLUDES PISTON & SEALS) |
| 15. | 1G-5763 | [1] | SEAL-O-RING | |
| 16. | 108-3001 | [1] | SWASHPLATE | |
| 17. | 5E-8784M | [4] | BOLT(M6X1X20-MM) | |
| 18. | 260-6637 | [1] | PLATE-VALVE | |
| 19. | 1G-5745 | [1] | KIT-CYLINDER BLOCK | |
| | | | (INCLUDES SEAT, SPRING, RETAINER, RETAINING RING & CYLINDER BLOCK) |
| 20. | 1G-5772 | [1] | KIT-PISTON BLOCK | |
| 21. | 5E-8738 | [1] | SPRING | |
| 22. | 108-3002 | [1] | BLOCK-SLIDER | |
| 23. | 134-1824 | [1] | BOLT(M10X1.5X35-MM) | |
| 24. | 134-1825 | [1] | BOLT(M8X1.25X50-MM) | |
| 25. | 1G-5744 | [1] | BEARING | |
| 26. | 5E-8747 | [2] | VALVE-CHECK | |
| 27. | 5E-8777 | [2] | PLUG | |
| 28. | 1G-5764 | [1] | BEARING | |
| 29. | 3J-1907 | [4] | SEAL-O-RING | |
| 30. | 9S-4191 | [4] | PLUG(9/16-18-THD) | |
| 31. | 5E-8743 | [2] | BUSHING-TERMINAL | |
| 32. | 229-8394 | [1] | PLATE-COVER | |
| 33. | 6V-8837M | [6] | BOLT(M6X1X16-MM) | |
| 34. | 170-4717 | [1] | SEAL-O-RING | |
| 35. | 7X-9294 | [1] | COVER | |
| 36. | 6H-1717 | [2] | BOLT(1/2-13X1.125-IN) | |
| 37. | 096-0008M | [4] | BOLT-SOCKET HEAD(M16X2X140-MM) | |
| 38. | 5E-8771 | [1] | SEAL-O-RING | |
| 39. | 109-5166 | [1] | COVER-CHARGE | |
| 40. | 109-5164 | [1] | PUMP-CHARGE | |
| 41. | 1G-5767 | [1] | PIN | |
| 42. | 109-5165 | [1] | SHAFT-CHARGE | |
| 43. | 7R-3453 | [1] | KEY-WOODRUFF | |
| 44. | 5E-9816 | [2] | SEAL-O-RING | |
| 45. | 8J-2413 | [2] | SEAL-O-RING | |
| 46. | 229-8393 | [2] | KIT-VALVE | |
| | | | (EACH INCLUDES VALVE & O-RING SEALS) |
| 47. | 5E-8750 | [1] | TUBE | |
| 48. | 7M-8485 | [1] | SEAL-O-RING | |
| 49. | 5E-8764 | [1] | NUT(1-5/16-12-THD) | |
| 50. | 107-5896 | [1] | KIT-MANIFOLD | |
| | | | (INCLUDES ADAPTER AS & PLUG AS) |
| 51. | 1G-5737 | [1] | BEARING | |
| | M | | METRIC PART |
| | Y | | SEPARATE ILLUSTRATION |
