卡特零件查询（AP-1055D） 105-6640: BOGIE GP-REAR
广数供应链运营团队, 16 02月, 2025，浏览：
900 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 231-3079CY | [4] | ROLLER GP-TRACK(SINGLE FLANGE) | |
| 2. | 107-4050 | [1] | FRAME AS-BOGIE | |
| | 105-9056 | [2] | BUSHING | |
| 3. | 107-7885 | [1] | CAP | |
| 4. | 5P-2566 | [20] | BOLT(1/2-13X1.5-IN) | |
| 5. | 8T-4223 | [22] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 6. | 107-8252 | [1] | CAP | |
| 7. | 4L-6454 | [3] | BOLT(3/8-16X1-IN) | |
| 8. | 8T-4896 | [3] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 9. | 8T-9384 | [2] | BOLT(1/2-13X0.875-IN) | |
| 10. | 114-6094B | [2] | SHIM(0.51-MM THK) | |
| 11. | 114-6095B | [2] | SHIM(1.52-MM THK) | |
| 12. | 124-0238B | [8] | SHIM(0.51-MM THK) | |
| 13. | 124-0239B | [8] | SHIM(1.52-MM THK) | |
| 14. | 107-9130B | [4] | SHIM(3.18-MM THK) | |
| 15. | 107-9131B | [4] | SHIM(1.59-MM THK) | |
| 16. | 124-0237 | [2] | RING | |
| 17. | 3B-8489 | [1] | FITTING-GREASE(1/8-27 PTF) | |
| | B | | USE AS REQUIRED |
| | C | | CHANGE FROM PREVIOUS TYPE |
| | Y | | SEPARATE ILLUSTRATION |
