卡特零件查询（AP-1055D） 239-3467: CONTROL GP-GRADE & SLOPE
广数供应链运营团队, 16 02月, 2025，浏览：
146 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 3S-2093 | [5] | STRAP-CABLE | |
| 2. | 6V-2480 | [10] | SCREW(4-40X0.5-IN) | |
| 3. | 8C-8270 | [2] | BRACKET AS | |
| 4. | 8C-8272 | [2] | SUPPORT AS | |
| | | | (EACH INCLUDES) |
| | 8T-5912 | [4] | NUT-WELD(3/8-16-THD) | |
| 5. | 8C-8273 | [4] | BOLT-SPECIAL | |
| 6. | 8C-8288 | [2] | EXTENSION | |
| 7. | 8T-4571 | [8] | FLANGE-HALF | |
| 8. | 9B-1117 | [10] | LOCKWASHER | |
| 9. | 122-9836 | [2] | BRACKET-MOUNTING | |
| 10. | 130-2985 | [2] | MOUNT AS | |
| 11. | 130-2987 | [2] | PLATE | |
| 12. | 133-6089 | [2] | SUPPORT AS | |
| 13. | 288-6319 | [1] | SENSOR-SLOPE | |
| 14. | 168-5031Y | [2] | CONTROL GP-GRADE & SLOPE | |
| 15. | 189-5761 | [1] | BRACKET | |
| 16. | 192-3287 | [2] | BRACKET | |
| 17. | 197-5820 | [1] | SUPPORT | |
| 18. | 197-7228 | [2] | SUPPORT AS | |
| 19. | 203-6073 | [1] | HARNESS AS-CONTROL(GRADE, SLOPE) | |
| 20. | 203-6074 | [2] | HARNESS AS-SCREED(GRADE, SLOPE) | |
| 21. | 4B-4863 | [4] | WASHER(4.7X11X1.2-MM THK) | |
| 22. | 5P-2228 | [8] | BOLT(1/2-13X1-IN) | |
| 23. | 5P-2675 | [4] | BOLT(1/4-20X1.75-IN) | |
| 24. | 5P-8167 | [8] | BOLT(3/8-16X0.625-IN) | |
| 25. | 5S-7383 | [16] | BOLT(3/8-16X1.75-IN) | |
| 26. | 6B-4540 | [10] | NUT(4-40-THD) | |
| 27. | 6V-5782 | [2] | BOLT(5/16-18X1.125-IN) | |
| 28. | 6V-8185 | [12] | NUT(1/4-20-THD) | |
| 29. | 6V-8189 | [6] | NUT(5/16-18-THD) | |
| 30. | 6V-8801 | [24] | NUT(3/8-16-THD) | |
| 31. | 6V-8918 | [4] | BOLT(5/16-18X1.25-IN) | |
| 32. | 7K-1181 | [9] | STRAP-CABLE | |
| 33. | 8T-4205 | [24] | WASHER-HARD(7.2X14.5X2-MM THK) | |
| 34. | 8T-4223 | [24] | WASHER-HARD(13.5X25.5X3-MM THK) | |
| 35. | 8T-4224 | [12] | WASHER-HARD(8.8X16X2-MM THK) | |
| 36. | 8T-4896 | [48] | WASHER-HARD(10.2X18.5X2.5-MM THK) | |
| 37. | 8T-8908 | [8] | BOLT(1/4-20X1-IN) | |
| 38. | 8T-8917 | [16] | BOLT(1/2-13X1.25-IN) | |
| 39. | 9B-7237 | [4] | BOLT(3/8-16X1.25-IN) | |
| 40. | 9X-8486 | [4] | SCREW-MACHINE(8-32X0.75-IN) | |
| | R | | REMANUFACTURED PART MAY BE AVAILABLE |
| | Y | | SEPARATE ILLUSTRATION |
