卡特零件查询（AP-1055E） 368-2981: FILTER GP-ENGINE OIL
广数供应链运营团队, 16 02月, 2025，浏览：
865 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 8C-3445 | [1] | CAP-DUST | |
| 2. | 177-2215 | [2] | STRAP-DUAL CLAMP | |
| 3. | 7K-1181 | [2] | STRAP-CABLE | |
| 4. | 338-1553 | [1] | PLATE | |
| 5. | 340-4212 | [1] | ADAPTER | |
| 6. | 368-0589I | [1] | HOSE AS | |
| 7. | 368-0597I | [1] | HOSE AS | |
| 8. | 148-8322 | [2] | CONNECTOR AS | |
| | | | (EACH INCLUDES) |
| | 2M-9780 | [1] | SEAL-O-RING | |
| | 6V-8640 | [1] | CONNECTOR | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| 9. | 148-8339 | [1] | CONNECTOR AS | |
| | 6V-8716 | [1] | CONNECTOR(STRAIGHT) | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| | 7M-8485 | [1] | SEAL-O-RING | |
| 10. | 148-8344 | [1] | CONNECTOR AS | |
| | 3D-2824 | [1] | SEAL-O-RING | |
| | 6V-9162 | [1] | CONNECTOR | |
| | 6V-9746 | [1] | SEAL-O-RING | |
| 11. | 164-5590 | [1] | VALVE AS-FLUID SAMPLING(ENGINE OIL) | |
| | 3J-7354 | [1] | SEAL-O-RING | |
| | 8C-3446 | [1] | VALVE-SAMPLING(ENGINE OIL) | |
| 12. | 225-7944 | [2] | GASKET | |
| 13. | 4P-7429 | [2] | CLIP(LADDER) | |
| 14. | 8T-4121 | [2] | WASHER-HARD(11X21X2.5-MM THK) | |
| 15. | 8T-4185M | [2] | BOLT(M10X1.5X50-MM) | |
| 16. | 8T-4224 | [4] | WASHER-HARD(8.8X16X2-MM THK) | |
| 17. | 8T-7547M | [4] | BOLT(M8X1.25X30-MM) | |
| 18. | 8T-7859 | [1] | CONNECTOR | |
| 19. | 8T-7876 | [1] | SEAL-O-RING | |
| | I | | REFER TO HYDRAULIC INFORMATION SYSTEM |
| | M | | METRIC PART |
